Specification Basic Information Supported CPU Supports AMD Ryzen 7000 Series Desktop Processors Socket AM5 Chipset AMD X670 Form Factor ATX 243.84mmx304.8mm Audio Realtek ALC4080 Codec 7.1-Channel High Definition Audio Supports S/PDIF output Supports up to 32-Bit/384 kHz playback on front panel Expansion Slots PCI 3x PCI-E x16 slot Supports x16/x4/x2 1x PCI-E x1 slot PCI_E1 PCIe 4.0 supports up to x16 (From CPU) PCI_E2 PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 PCIe 4.0 supports up to x4 (From CPU) PCI_E4 PCIe 4.0 supports up to x2 (From Chipset) Memory Type DDR5 Slots 4 DIMMs Supported Memory Dual Channel DDR5 Maximum Memory 128GB Graphics Graphics 1x HDMI Support HDMITM 2.1 FRL, maximum resolution of 4K 120Hz 1x Display Port Supports DP1.4, maximum resolution of 4K 60Hz 1x Type-C Display port Supports DisplayPort 1.4 with HBR3, maximum resolution of 4K 120Hz Connector & Ports HDMI 1x HDMI Display Port (s) 1x Display Port USB (s) 4x USB 2.0 ports (Front) 4x USB 3.2 Gen1 Type A ports (Rear) 4x USB 3.2 Gen1 Type A ports (Front) 2x USB 3.2 Gen2 Type A ports (Rear) 1x USB 3.2 Gen2 Type C ports (Rear) 1x USB 3.2 Gen2 Type C ports (Front) 1x USB 3.2 Gen2x2 Type C ports (Rear) LAN Port (s) Realtek RTL8125BG 2.5G LAN Wireless Communication module AMD Wi-Fi 6E The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX Supports 20MHz, 40MHz, 80MHz,160MHz bandwidth in 2.4GHz/ 5GHz or 6GHz* bands Supports 802.11 a/ b/ g/ n/ ac/ ax Supports Bluetooth 5.2 Supported Storage 4x M.2 slot M.2_1 (From CPU) supports up to PCIe 5.0 x4 , supports 22110/2280 devices M.2_2 (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices M.2_3 (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices M.2_4 (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices 6x SATA 6G port RAID Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices Internal I/O Ports 1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x CPU Fan 1x Pump Fan 6x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Tuning Controller connector(JDASH) 2x Addressable V2 RGB LED connector (JARGB_V2) 2x RGB LED connector(JRGB) 4x USB 2.0 ports 4x USB 3.2 Gen1 Type A ports 1x USB 3.2 Gen2 Type C ports Warranty Information Manufacturing Warranty 3 Years MSI PRO X670-P WIFI DDR5 AMD AM5 ATX Motherboard The MSI PRO X670-P WIFI Motherboard supports AMD Ryzen 7000-series CPUs with up to 16 Zen 4 cores and dual-channel DDR5 RAM with a Maximum Memory Capacity of up to 128GB. It has a 14+2+1 Duet Rail Power System, a double 8-pin CPU power connector, Core Boost, and Memory Boost. This motherboard is made to provide an uninterrupted gaming experience on a high-performance PC. It has a bigger heatsink, 7W/mK MOSFET thermal pads, more thermal pads for the choke, and a double-sided M.2 shield Frozr. An 8-layer PCB made of server-grade components and copper that is 2 oz thicker is used to build the motherboard. Maximum storage performance is provided by the onboard and unique M.2 XPANDER-Z GEN5 DUAL PCI-Express card offered by the MSI PRO X670-P WIFI Motherboard. With PCIe 4.0 slots, Lightning Gen 5 x4 M.2, and USB 3.2 Gen 2x2 it can give a lightning-fast gaming experience. The double-sided Shield Frozr architecture makes M.2 SSDs quicker while keeping them safe and reducing throttling. The rear I/O panel now provides quick access to Turbo mode, a one-click toggle for all RGB lights, and direct safe boot entry. There are 4 M.2 slots and 2 PCIe Gen 5 x16 slots available on the MSI PRO X670-P WIFI. For efficient heat dissipation from the VRMs, the MEG series includes a MOSFET baseplate, a heatpipe, and a stacked fin array heatsink. The warranty period for the MSI PRO X670-P WIFI Motherboard is three years. ..
