MSI PRO B840-S EVO WIFI6E AM5 DDR5 Motherboard

Status
In Stock
3 stores
Lowest 20,800 BDT
Price Range 20,800 to 21,500 BDT Save 3%
MSI PRO B840-S EVO WIFI6E AM5 DDR5 Motherboard

Product Description

Engineered by MSI, this motherboard is designed for **AM5** socket processors, featuring a **Micro-ATX** form factor, and supporting high-speed **DDR5** memory, providing a reliable foundation for custom desktop systems. Currently, the lowest price in Bangladesh for this item is **20,800 ৳**, with active inventory listings tracked from UCC, Ultra Technology, Skyland BD.
Part ID: #CAN-10401 Last Updated: 6 hours ago

Available Deals & Price Comparison

Prices updated daily
Retailer Stock Status Price Last Checked Action
Ultra Technology MSI PRO B840-S EVO WIFI6E AM5 DDR5 Motherboard
In Stock 20,800 6 hours ago
Skyland BD MSI PRO B840-S EVO WIFI6E AM5 DDR5 Motherboard
In Stock 20,800 6 hours ago
UCC MSI PRO B840-S EVO WIFI6E AM5 DDR5 Motherboard
In Stock 21,500 6 hours ago

Historical Pricing Trend

Product Specifications

General Information

Audio Realtek® ALC897 7.1-Channel High Definition Audio
Chipset Model AMD B840
Form Factor m-ATX 243.84mmx304.8mm
LAN Realtek® 8125D 2.5G LAN
Memory 4x DDR5 UDIMM, Maximum Memory Capacity 256GB Memory Support DDR5 8000 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/s Ryzen™ 9000 Series Processors max. overclocking frequency: • 1DPC 1R Max speed up to 8000+ MT/s • 1DPC 2R Max speed up to 6400+ MT/s • 2DPC 1R Max speed up to 6400+ MT/s • 2DPC 2R Max speed up to 5600+ MT/s Supports AMD POR Speed and JEDEC Speed Supports Memory Overclocking and AMD EXPOTM Supports Dual-Channel mode Supports Non-ECC, Un-buffered memory Supports CUDIMM, Clock Driver bypass mode only* * CUDIMM support and POR boot frequency may vary by CPU series, with manual overclocking available after boot. Certain CPUs may fail to boot, but future BIOS updates will improve compatibility. • The DIMM slots on this motherboard only have single-sided latches.
Slots 2x M.2 M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices 4x SATA 6G M2_2 slot • Supports up to PCIe 4.0 x4 • Supports up to PCIe 4.0 x2 (For Ryzen™ 8500/ 8300 Series processors) *Please refer to the manual for M.2 SSD heatsink restrictions. 1x PCI-E x16 slot 1x PCI-E x1 slot PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E1 slot • Supports PCIe 4.0 x16 (For Ryzen™ 9000/ 7000 Series processors) • Supports PCIe 4.0 x8 (For Ryzen™ 8700/ 8600/ 8400 Series processors) • Supports PCIe 4.0 x4 (For Ryzen™ 8500/ 8300 Series processors)
Socket AM5

Network & Connectivity

WiFi Wi-Fi 6E The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz* (160MHz) up to 2.4Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax Supports Bluetooth® 5.3**, FIPS, FISMA * 6GHz band support may depend on every country’s regulations and Wi-Fi 6E will be ready in Windows 11 version 24H2. ** The Bluetooth version may be updated, please refer to the Wi-Fi chipset vendor’s website for details. Bluetooth 5.4 will be ready in Windows 11 version 24H2.

Main Features

Supported CPU Supports AMD Ryzen™ 9000/ 8000/ 7000 Series Desktop Processors

Connectivity

HDMI 1x HDMI™ Support HDMITM 2.1, maximum resolution of 4K 60Hz* *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.
USB Port (s) 4x USB 2.0 (Rear) 4x USB 2.0 (Front) 2x USB 5Gbps Type A (Rear) 2x USB 5Gbps Type A (Front) 1x USB 5Gbps Type C (Front) 1x USB 10Gbps Type A (Rear) 1x USB 10Gbps Type C (Rear)

Connector & ports

Internal I/O Ports 1x Power Connector(ATX_PWR) 1x Power Connector(CPU_PWR) 1x CPU Fan 1x Combo Fan (Pump_Sys Fan) 3x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM) 1x Tuning Controller connector(JDASH) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 5Gbps Type A ports 1x USB 5Gbps Type C ports

Expansion Slots

PCI 1x PCI-E x16 slot 1x PCI-E x1 slot PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E1 slot • Supports PCIe 4.0 x16 (For Ryzen™ 9000/ 7000 Series processors) • Supports PCIe 4.0 x8 (For Ryzen™ 8700/ 8600/ 8400 Series processors) • Supports PCIe 4.0 x4 (For Ryzen™ 8500/ 8300 Series processors)

Warranty Information

Warrantty 3 Years Warranty
Part ID: #CAN-10401 Last Updated: 6 hours ago
for Modern Gaming and High-Performance ComputingThe MSI PRO B840-S EVO WIFI6E AM5 DDR5 Motherboard is designed for users who want reliable performance, modern connectivity, and excellent compatibility for AMD Ryzen desktop processors. Built with the AMD B840 chipset and AM5 socket, this motherboard supports AMD Ryzen 9000, 8000, and 7000 Series processors, making it an excellent choice for building a powerful gaming PC, professional workstation, or everyday desktop system.Featuring four DDR5 UDIMM memory slots, the motherboard supports up to 256GB of memory and provides high-speed DDR5 performance with memory overclocking and AMD EXPO support. This helps users enjoy smoother multitasking, faster application performance, and improved overall system responsiveness.The MSI PRO B840-S EVO WIFI6E AM5 DDR5 Motherboard comes with Wi-Fi 6E for fast wireless networking across compatible 2.4GHz, 5GHz, and 6GHz bands. It also includes Bluetooth support and Realtek 2.5G LAN, providing flexible and reliable networking options for gaming, streaming, downloading, and professional work.For storage expansion, the motherboard offers two M.2 slots supporting PCIe 4.0 x4 devices along with four SATA 6Gbps ports. PCIe expansion includes a PCIe 4.0 x16 slot for compatible graphics cards and a PCIe 3.0 x1 slot for additional expansion devices. With multiple USB connectivity options, including USB 10Gbps Type-A and Type-C ports, users can easily connect modern peripherals and high-speed devices.The motherboard also features HDMI 2.1 support with up to 4K 60Hz output when using a compatible processor with integrated graphics. With a 3-year warranty, the MSI PRO B840-S EVO WIFI6E AM5 DDR5 Motherboard is a dependable solution for users planning a modern AMD AM5 desktop build.Why Choose the MSI PRO B840-S EVO WIFI6E AM5 DDR5 Motherboard?AMD B840 Chipset provides reliable performance for modern AM5 desktop systems.AM5 Socket Support works with AMD Ryzen 9000, 8000, and 7000 Series processors.DDR5 Memory Support supports up to 256GB capacity for demanding workloads.Memory Overclocking and AMD EXPO support help optimize DDR5 performance.Wi-Fi 6E Connectivity delivers fast and advanced wireless networking capabilities.2.5G LAN provides high-speed wired networking for gaming and professional use.Dual PCIe 4.0 M.2 Slots support high-speed NVMe SSD storage.Multiple USB Ports provide flexible connectivity for modern peripherals.HDMI 2.1 Support enables up to 4K 60Hz output with compatible processors.3 Years Warranty provides dependable long-term product support.Real Buyer Reviews and Ratings for MSI PRO B840-S EVO WIFI6E AM5 DDR5 MotherboardUsers looking for a modern AM5 motherboard will appreciate the MSI PRO B840-S EVO WIFI6E AM5 DDR5 Motherboard for its DDR5 memory support, Wi-Fi 6E connectivity, 2.5G LAN, and flexible expansion options. The combination of AMD Ryzen processor compatibility, PCIe 4.0 storage support, and multiple high-speed USB ports makes it a practical choice for gaming, productivity, content creation, and everyday computing.Build a Modern AMD AM5 PC with MSI PRO B840-S EVO WIFI6EIf you are planning to build a new AMD Ryzen desktop PC, the MSI PRO B840-S EVO WIFI6E AM5 DDR5 Motherboard offers the modern features needed for a fast and future-ready system. With DDR5 memory support, Wi-Fi 6E, 2.5G LAN, PCIe 4.0 M.2 storage, and broad AMD Ryzen processor compatibility, it provides an excellent foundation for gaming and professional computing.Why Buy from Ultra Technology?Ultra Technology is your trusted destination for authentic tech products at competitive prices in Bangladesh. We provide genuine products from authorized distributors and reputable brands to ensure quality and reliability. Our knowledgeable team is always ready to help you choose the right product according to your requirements and budget. With nationwide delivery, responsive customer service, and dependable after-sales support, Ultra Technology is committed to providing a smooth and hassle-free shopping experience.Frequently Asked Questions (FAQ)Q1: Which processors are supported by this motherboard?A: It supports AMD Ryzen 9000, 8000, and 7000 Series Desktop Processors.Q2: Does this motherboard support DDR5 RAM?A: Yes, it has four DDR5 UDIMM slots and supports up to 256GB memory capacity.Q3: Does it have built-in Wi-Fi?A: Yes, the motherboard features built-in Wi-Fi 6E connectivity.Q4: How many M.2 SSD slots are available?A: It includes two M.2 slots supporting compatible PCIe 4.0 storage devices.Q5: What warranty does this motherboard include?A: The MSI PRO B840-S EVO WIFI6E AM5 DDR5 Motherboard comes with a 3-year warranty...
