MSI PRO B660M-A WIFI DDR5 MICRO-ATX 12TH GEN INTEL MOTHERBOARD

Status
In Stock
2 stores
Lowest 20,500 BDT
Price Range Single price listing
MSI PRO B660M-A WIFI DDR5 MICRO-ATX 12TH GEN INTEL MOTHERBOARD

Product Description

Unlock Your Gaming Potential with MSI PRO B660M-A WIFI DDR5

Designed for enthusiasts and professionals, the MSI PRO B660M-A WIFI DDR5 motherboard is the perfect choice for those seeking a robust and feature-rich platform for their 12th Gen Intel Core processors. With its cutting-edge technology and high-quality assembly, this motherboard delivers an efficient and productive experience, making it ideal for demanding workflows and gaming applications.

Key Features and Benefits
  • Supports 12th Gen Intel Core processors and up to 128GB of DDR5 memory
  • Two PCIe 4.0 x16 slots and one PCIe 3.0 x1 slot for flexible expansion options
  • Four SATA 6Gb/s ports and two M.2 slots for high-speed storage solutions
  • Intel Wi-Fi 6 with MU-MIMO and 2.4GHz/5GHz dual-band support
  • Realtek ALC897 codec and 7.1-channel high-definition audio
MSI's Proprietary Technologies

M.2 Shield Frozr keeps M.2 SSDs safe while preventing throttling, making them run faster. Frozr AI Cooling detects CPU & GPU temperatures and automatically adjusts system fan duty to a proper value, ensuring optimal cooling performance. Memory Boost delivers pure data signals for the best performance, stability, and compatibility, while Core Boost combines MSI's premium layout and optimized power design for faster and undistorted current delivery to the CPU.

Part ID: #CAN-01644 Last Updated: 1 month ago

Available Deals & Price Comparison

Prices updated daily
Retailer Stock Status Price Last Checked Action
PC House MSI PRO B660M-A WIFI DDR5 MICRO-ATX 12TH GEN INTEL MOTHERBOARD
In Stock 20,500 1 month ago
Buy Now
TechLand BD MSI PRO B660M-A WIFI DDR5 MICRO-ATX 12TH GEN INTEL MOTHERBOARD
Check Stock 20,500 5 hours ago
Buy Now

Historical Pricing Trend

Product Specifications

General Specifications

LAN 1x Realtek RTL8125BG 2.5Gbps LAN controller
USB 1x USB 3.2 Gen 1 5Gbps Type-C connector (From B660 chipset) 1x USB 3.2 Gen 1 5Gbps Type-A connector (From ASM1074) Supports additional 2 USB 3.2 Gen 1 5Gbps ports 2x USB 2.0 Type-A connectors (From B660 chipset) Supports additional 4 USB 2.0 ports
WiFi Intel Wi-Fi 6 The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz (160MHz) up to 2.4Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax
Audio Realtek ALC897 Codec 7.1-Channel High Definition Audio
Slots 2x PCIe x16 slots PCI_E1 (From CPU) Support PCIe 4.0 x16 PCI_E3 (From B660 chipset) Support PCIe 3.0 x4 1x PCIe 3.0 x1 slot (Fom B660 chipset)
Memory 4x DDR5 memory slots, support up to 128GB Supports 1R 4800 MHz (by JEDEC & POR) Max overclocking frequency: 1DPC 1R Max speed up to 6200+ MHz 1DPC 2R Max speed up to 5200+ MHz 2DPC 1R Max speed up to 4000+ MHz 2DPC 2R Max speed up to 4000+ MHz Supports Dual-Channel mode Supports non-ECC, un-buffered memory Supports Intel® Extreme Memory Profile (XMP)
Chipset Intel B660 Chipset
Graphics 2x HDMI 2.1 with HDR ports, supporting a maximum resolution of 4K 60Hz 2x DisplayPort 1.4 ports with HBR3, supporting a maximum resolution of 4K 60Hz
Warranty 03 Years
Bluetooth Supports Bluetooth® 5.2
Dimension 9.6 in. x 9.6 in. (24.4 cm x 24.4 cm)
Form Factor Micro-ATX Form Factor
Supported CPU Supports 12th Gen Intel Core Processors Processor socket LGA1700
Supported Storage 4x SATA 6Gb/s ports (From B660 chipset) 2x M.2 slots (Key M) M2_1 slot (From CPU) Supports up to PCIe 4.0 x4 Supports 2242/ 2260/ 2280 storage devices M2_2 slot (From B660 chipset) Supports up to PCIe 4.0 x4 Supports up to SATA 6Gb/s Supports 2242/ 2260/ 2280 storage devices Supports Intel Optane Memory Support Intel Smart Response Technology for Intel Core processors
External I/O Ports Keyboard / Mouse DisplayPort USB 3.2 Gen 1 5Gbps Type-A LAN port Wi-Fi / Bluetooth Audio connector USB 2.0 HDMI USB 3.2 Gen 2 10Gbps Type-A
Internal I/O Ports 1x Front panel audio connector 2x System panel connectors 1x Chassis Intrusion connector 1x TPM module connector 1x Tuning Controller connector 1x TBT connector (supports RTD3) 1x Serial port
Part ID: #CAN-01644 Last Updated: 1 month ago
