MSI PRO B550M-B AMD AM4 mATX Motherboard

Product Description

MSI PRO B550M-B AMD AM4 mATX Motherboard

Unlock Unbeatable Performance for Mainstream PC Builders

The MSI PRO B550M-B Motherboard is designed for PC builders who demand stability, performance, and essential features at a great value. Built on the AMD B550 chipset with support for the AM4 socket, it is fully compatible with a wide range of AMD Ryzen 3000, 4000, and 5000 series processors, making it a versatile choice for gaming and productivity.

Key Features and Benefits

  • Supports AMD Ryzen 5000 Series, 5000 G-Series, 4000 G-Series, 3000 Series, and 3000 G-Series desktop processors Socket AM4.
  • 2x DDR4 slots with support for up to 64GB of memory and speeds reaching 4400+ MHz (OC).
  • PCIe 4.0 support for next-gen graphics cards and NVMe SSDs, delivering ultra-fast data transfer speeds.
  • 2x M.2 slots with PCIe 4.0/3.0 support and multiple SATA ports for flexible storage options.
  • Realtek 1Gbps LAN and USB 3.2 Gen1 ports for stable networking and versatile connectivity.

Proprietary Technologies and Advantages

Enhanced Performance and Reliability

The MSI PRO B550M-B Motherboard features Core Boost technology, Audio Boost, and premium thermal solutions, providing reliable power delivery, improved sound quality, and efficient cooling for long-term durability. Its compact micro-ATX form factor fits easily into smaller cases while still offering robust functionality, making it an ideal choice for budget-friendly gaming rigs and productivity workstations.

Part ID: #CAN-00977 Last Updated: 4 hours ago

Available Deals & Price Comparison

Prices updated daily
Retailer Stock Status Price Last Checked Action
Star Tech MSI PRO B550M-B AMD AM4 mATX Motherboard
In Stock 11,500 3 hours ago
Buy Now
Skyland BD MSI PRO B550M-B DDR4 AMD AM4 Micro ATX Motherboard
In Stock 11,500 2 hours ago
Buy Now

Historical Pricing Trend

Product Specifications

Basic Information

Supported CPU Supports AMD Ryzen 5000 Series, 5000 G-Series, 4000 G-Series, 3000 Series and 3000 G-Series desktop processors Socket AM4
Chipset AMD B550
Form Factor mATX 220mmx243.84mm
Audio Realtek ALC897 Codec 7.1-Channel High Definition Audio

Expansion Slots

PCI 1x PCI-E x16 slot PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU)
M.2 Socket 2x M.2 M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices M.2_2 Source (From Chipset) supports up to PCIe 3.0 x4 , supports 22110/2280 devices

Memory

Type DDR4
Slots 2x DDR4
Supported Memory Memory Support DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400/ 4600+ MHz by A-XMP OC MODE Max. overclocking frequency: • 1DPC 1R Max speed up to 4600+ MHz • 1DPC 2R Max speed up to 3866+ MHz
Maximum Memory up to 64GB

Graphics

Graphics 1x HDMI Support HDMITM 2.1, maximum resolution of 4K 60Hz* 1x DisplayPort Supports DP 1.2, maximum resolution of 4K 60Hz* *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.

Connector & Ports

HDMI 1x HDMI 2.1 port
Display Port (s) 1x DisplayPort 1.2
USB (s) 2x USB 2.0 (Rear) 4x USB 2.0 (Front) 4x USB 5Gbps Type A (Rear) 2x USB 5Gbps Type A (Front) 1x USB 5Gbps Type C (Front)
LAN Port (s) 1 x Realtek RTL8111H 1Gbps LAN
Supported Storage 2x M.2 M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices M.2_2 Source (From Chipset) supports up to PCIe 3.0 x4 , supports 22110/2280 devices 4x SATA 6G
Audio 1x Front Audio (JAUD)
Internal I/O Ports 1x Power Connector(ATX_PWR) 1x Power Connector(CPU_PWR) 1x CPU Fan 1x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 5Gbps Type A ports 1x USB 5Gbps Type C ports
TPM (Trusted Platform Module ) 1x TPM module connector

Others

Special Features 4x EZ Debug LED

Warranty Information

Manufacturing Warranty 3 Years

Key Features

Model PRO B550M-B
Supported CPU Ryzen 5000 & 3000 Series and Ryzen 4000 G-Series
Supported RAM 2 x DDR4 slots, Max 64GB, up to 4600+ MHz
Graphics Output 1x HDMI 2.1, 1x DP 1.2
Features 2x M.2 SSD Slot, Realtek 1Gbps LAN
