Product Description
Unleash the Power of AMD Ryzen
The MSI MPG X870E CARBON WIFI Motherboard is designed for enthusiasts and power users who demand exceptional performance and versatility. With its cutting-edge features and robust design, this motherboard is the perfect platform for building a high-performance PC that can tackle even the most demanding tasks.
Key Features and Benefits
- Supports AMD Ryzen 9000, 8000, and 7000 series desktop processors for exceptional performance and power efficiency
- Up to 256GB of DDR5 memory with overclocking rates of up to 8400 MT/s for seamless multitasking and content creation
- Three PCI-E x16 slots supporting PCIe 5.0 and 4.0 configurations for modern graphics cards and high-speed storage
- Onboard graphics options including HDMI 2.1 and two Type-C DisplayPort outputs for high-resolution video up to 8K at 60Hz
- Realtek ALC4080 Codec providing high-fidelity audio with 7.1-channel capability and S/PDIF output for immersive sound quality
Advanced Technologies and Features
The MSI MPG X870E CARBON WIFI Motherboard boasts an impressive array of advanced technologies and features, including:
- A powerful Wi-Fi 7 solution supporting MU-MIMO and Bluetooth 5.4 for seamless wireless connectivity
- A robust cooling system with numerous fan headers and compatibility for advanced cooling solutions
- RGB lighting with EZ Debug LED and EZ Digit Debug LED for a visually stunning appearance
Build Your Dream PC with the MSI MPG X870E CARBON WIFI Motherboard
Whether you're a gamer, content creator, or simply a power user, the MSI MPG X870E CARBON WIFI Motherboard is the perfect platform for building a high-performance PC that can tackle even the most demanding tasks.
Part ID: #CAN-01412
Last Updated: 1 month ago
Available Deals & Price Comparison
Prices updated daily| Retailer | Stock Status | Price | Last Checked | Action |
|---|---|---|---|---|
|
Star Tech
MSI MPG X870E CARBON WIFI AMD AM5 DDR5 ATX Motherboard
|
In Stock | Call for Price | 1 week ago | |
|
Ultra Technology
MSI MPG X870E CARBON WIFI DDR5 AMD AM5 ATX Motherboard
|
In Stock | 63,900 | 5 hours ago | |
|
Creatus Computer
MSI MPG X870E CARBON WIFI DDR5 AMD AM5 ATX Motherboard
|
In Stock | 64,000 | 5 hours ago | |
|
TechLand BD
MSI MPG X870E Carbon Wifi DDR5 AMD AM5 ATX Motherboard
|
In Stock | 65,500 | 5 hours ago | |
|
UCC
MSI MPG X870E CARBON WIFI DDR5 AMD AM5 ATX Motherboard
|
In Stock | 65,500 | 5 hours ago | |
|
Computer Village
MSI MPG X870E CARBON WIFI DDR5 AMD AM5 ATX Motherboard
|
In Stock | 65,500 | 5 hours ago | |
|
Skyland BD
MSI MPG X870E CARBON WIFI AMD AM5 DDR5 ATX Motherboard
|
Check Stock | 64,500 | 4 hours ago | |
|
PCB Store
MSI MPG X870E CARBON WIFI AM5 DDR5 ATX Motherboard
|
Check Stock | 65,500 | 5 hours ago |
Historical Pricing Trend
Product Specifications
Basic Information
Supported CPU
Supports AMD Ryzen 9000/ 8000/ 7000 Series Desktop Processors Socket AM5
Chipset
AMD X870E
Form Factor
ATX 243.84mmx304.8mm
Audio
Realtek ALC4080 Codec 7.1-Channel USB High-Performance Audio Supports up to 32-Bit/384 kHz playback on front panel Supports S/PDIF output
Expansion Slots
PCI
3x PCI-E x16 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 5.0 supports up to x4 (From CPU) PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) PCI_E1 & PCI_E2 slots • Supports PCIe 5.0 x16/x0 or x8/x4 (For Ryzen™ 9000/ 7000 Series processors) • Supports PCIe 4.0 x8/x0 (For Ryzen™ 8700/ 8600/ 8400 Series processors) • Supports PCIe 4.0 x4/x0 (For Ryzen™ 8500/ 8300 Series processor) PCI_E3 slot • Supports up to PCIe 4.0 x4 * PCI_E1 & PCI_E2 & M.2_2 share the bandwidth, and PCIe version support varies depending on the CPU. Please refer to the PCIe configuration table in the manual for more details.
M.2 Socket
4x M.2 M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices M.2_2 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 22110/2280 devices M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
Memory
Type
DDR5
Slots
4 DIMMs
Supported Memory
Memory Support DDR5 8400 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/s Ryzen 9000 Series Processors max. overclocking frequency: 1DPC 1R Max speed up to 8400+ MT/s 1DPC 2R Max speed up to 6400+ MT/s 2DPC 1R Max speed up to 6400+ MT/s 2DPC 2R Max speed up to 4800+ MT/s
Maximum Memory
256GB
Graphics
Graphics
1x HDMI Support HDMITM 2.1 with FRL port, maximum resolution of 8K 60Hz 2x Type-C DisplayPort USB4 port, supporting DisplayPort 1.4 with HBR3 over USB Type-C, maximum resolution of 4K@60Hz
Connector & Ports
HDMI
1x HDMI
Display Port (s)
2x Type-C DisplayPort
USB (s)
4x USB 2.0 (Front) 4x USB 5Gbps Type A (Front) 9x USB 10Gbps Type A (Rear) 2x USB 10Gbps Type C (Rear) 1x USB 20Gbps Type C (Front) 2x USB 40Gbps Type C (Rear)
LAN Port (s)
1x Realtek 8126 5G LAN 1x Realtek 8125 2.5G LAN
Wireless Communication module
Wi-Fi 7 Solution The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz* (320MHz) up to 5.8Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax/ be Supports Bluetooth 5.4, MLO, 4KQAM
Supported Storage
4x M.2 M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices M.2_2 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 22110/2280 devices M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices 4x SATA 6G M.2_1 slot • Supports up to PCIe 5.0 x4 (For Ryzen 9000/ 7000 Series processors) • Supports up to PCIe 4.0 x4 (For Ryzen 8000 Series processors) M.2_2 slot* • Supports up to PCIe 5.0 x4 (For Ryzen 9000/ 7000 Series processors) • The M2_2 slot will be unavailable when using Ryzen 8000 Series processors
RAID
Supports RAID 0, RAID 1 and Raid 10 for SATA storage devices Supports RAID 0, RAID 1 and Raid 10* for M.2 NVMe storage devices
Internal I/O Ports
1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x Power Connector(PCIE_PWR 8pin) 1x CPU Fan 1x Combo Fan (Pump_Sys Fan) 5x System Fan 1x EZ Conn-header (JAF_2) 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Thermal Sensor connectors(T_SEN) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 4x USB 2.0 ports 4x USB 5Gbps Type A ports 1x USB 20Gbps Type C ports
Warranty Information
Manufacturing Warranty
3 Years
Key Features
Model
MPG X870E CARBON WIFI
Supported CPU
Ryzen 9000/ 8000/ 7000 Series for Socket AM5
Supported RAM
4x DDR5, Up to 8400-5600 (OC) MT/s
Graphics Output
1x HDMI, 2x Type-C DisplayPort
Features
1x 2.5G LAN, 1x 5G LAN, Wi-Fi 7, Bluetooth 5.4
Part ID: #CAN-01412
Last Updated: 1 month ago
