MSI MEG Z790 ACE 13TH & 12TH GEN E-ATX MOTHERBOARD

Product Description

Unleash Your Gaming Potential with the MSI MEG Z790 ACE

Designed for extreme overclocking enthusiasts and power users, the MSI MEG Z790 ACE motherboard is the ultimate platform for those seeking unparalleled performance. Built on a robust E-ATX design, this motherboard is engineered to deliver exceptional power delivery, high-speed connectivity, and premium features for the most demanding applications.

Technical Specifications and Highlights

  • Supports 13th and 12th Gen Intel Core processors
  • High-quality 16+2+1 phase power delivery system for stable overclocking
  • High-speed Wi-Fi 6E and 2.5 GbE LAN for seamless networking
  • Quad Ultra-Fast NVMe M.2 slots with PCIe 5.0 support
  • High-quality audio capacitors and isolated audio circuitry for immersive sound
  • Supports up to 128 GB DDR5 memory with speeds up to 6400 MHz

Advanced Proprietary Technologies

The MSI MEG Z790 ACE motherboard features several innovative technologies that set it apart from the competition. MSI's proprietary Dragon Center software provides a centralized hub for monitoring and controlling system performance, while the motherboard's robust power delivery system ensures stable and efficient power delivery to the CPU and other components. Additionally, the motherboard's advanced cooling system, featuring MSI's patented Mystic Light technology, allows for customizable lighting effects and enhanced heat dissipation.

Part ID: #CAN-01625 Last Updated: 1 month ago

Available Deals & Price Comparison

Prices updated daily
Retailer Stock Status Price Last Checked Action
Creatus Computer MSI MEG Z790 ACE E-ATX Motherboard
In Stock 76,499 4 hours ago
Buy Now
Ultra Technology MSI MEG Z790 ACE 13th And 12th Gen E-ATX Motherboard
In Stock 76,900 3 hours ago
Buy Now
PC House MSI MEG Z790 ACE 13th and 12th Gen E-ATX Motherboard
Check Stock Call for Price 4 hours ago
Buy Now
Nexus Computer MSI MEG Z790 ACE 13th And 12th Gen DDR5 E-ATX Motherboard
Check Stock Call for Price 3 hours ago
Buy Now
TechLand BD MSI MEG Z790 ACE 13TH & 12TH GEN E-ATX MOTHERBOARD
Check Stock 74,500 4 hours ago
Buy Now
UCC MSI MEG Z790 ACE E-ATX Motherboard
Check Stock 75,900 4 hours ago
Buy Now

Historical Pricing Trend

Product Specifications

General Specifications

LAN 2x Intel 2.5Gbps LAN
USB 4x USB 2.0 (Front) 4x USB 3.2 Gen1 Type A (Front) 7x USB 3.2 Gen2 Type A (Rear) 1x USB 3.2 Gen2 Type C (Rear) 2x USB 3.2 Gen2x2 Type C (Front)
WiFi Intel Wi-Fi 6E The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz (160MHz) up to 2.4Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax
Audio Realtek ALC4082 Codec + ESS ES9280AQ Combo DAC/HPA 7.1-Channel USB High Performance Audio Supports S/PDIF output Supports up to 32-Bit/384 kHz playback on front panel
Slots 3x PCI-E x16 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 5.0 supports up to x8 (From CPU) PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset)
Memory 4x DDR5 UDIMM, Maximum Memory Capacity 192GB Memory Support 7800+(OC)/ 7600(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz Max. overclocking frequency: 1DPC 1R Max speed up to 7800+ MHz 1DPC 2R Max speed up to 6600+ MHz 2DPC 1R Max speed up to 6400+ MHz 2DPC 2R Max speed up to 5600+ MHz
Chipset INTEL Z790
Graphics 1x Type-C DisplayPort Supports a maximum resolution of 4K 60Hz
Warranty 3 Years
Bluetooth Supports Bluetooth 5.3
Dimension 277mmx304.8mm (E-ATX)
Multi-GPU AMD MULTI-GPU Support
Form Factor E-ATX
Supported CPU Supports 12th/13th Gen Intel Core Processors, Pentium® Gold and Celeron® Processors LGA 1700
Supported Storage 5x M.2 M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260 devices M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260 devices M.2_4 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280 devices M.2_5 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 22110/2280/2260 devices 6x SATA 6G
Internal I/O Ports 1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x Front Type-C Quick Charge Connector(PD_PWR1) 1x CPU Fan 2x Pump Fan 5x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Water Flow connector 1x Slow Mode Booting Jumper(JSLOW) 1x Front Audio (JAUD) 2x Thermal Sensor connectors(T_SEN) 1x Tuning Controller connector(JDASH) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 3.2 Gen1 Type A ports 2x USB 3.2 Gen 2x2 Type C ports V-check point
