Specification Basic Information Supported CPU Supports AMD Ryzen 7000 Series Desktop Processors Socket AM5 Chipset AMD X670 Form Factor E-ATX 288mmx304.8mm Audio Realtek ALC4082 Codec + ESS ES9280AQ Combo DAC/HPA 7.1-Channel High Definition Audio Supports S/PDIF output Supports up to 32-Bit/384 kHz playback on front panel Expansion Slots PCI 3x PCI-E x16 slot Supports x16/x0/x4, x8/x8/x4 PCI_E1 PCIe 5.0 supports up to x16 (From CPU) PCI_E2 PCIe 5.0 supports up to x8 (From CPU) PCI_E3 PCIe 5.0 supports up to x4 (From CPU) Memory Type DDR5 Slots 4 DIMMs Supported Memory Dual Channel DDR5 Maximum Memory 128GB Graphics Graphics Supports NVIDIA SLI Technology Supports AMD MULTI-GPU Connector & Ports USB (s) 4x USB 2.0 ports (Front) 4x USB 3.2 Gen1 Type A ports (Front) 7x USB 3.2 Gen2 Type A ports (Rear) 1x USB 3.2 Gen2 Type C ports (Front) 2x USB 3.2 Gen2x2 Type C ports (Rear) 1x USB 3.2 Gen2x2 Type C ports (Front) LAN Port (s) Marvell AQC113-B1-C 10Gbps LAN Intel I225V 2.5Gbps LAN Wireless Communication module AMD Wi-Fi 6E The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX Supports 20MHz, 40MHz, 80MHz,160MHz bandwidth in 2.4GHz/ 5GHz or 6GHz* bands Supports 802.11 a/ b/ g/ n/ ac/ ax Supports Bluetooth 5.2 Supported Storage 4x M.2 slot M.2_1 (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices M.2_2 (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices M.2_3 (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices M.2_4 (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices 8x SATA 6G port RAID Supports RAID 0, RAID 1, and RAID 10 for SATA storage devices Supports RAID 0, RAID 1, and RAID 10 for M.2 NVMe storage devices Internal I/O Ports 1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x Power Connector(PCIE_PWR 4pin or 6 pin) 1x Front Type-C Quick Charge Connector(PD_PWR1) 1x CPU Fan 2x Pump Fan 6x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Water Flow connector 1x Front Audio (JAUD) 2x Thermal Sensor connectors(T_SEN) 1x Tuning Controller connector(JDASH) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 4x USB 2.0 ports 4x USB 3.2 Gen1 Type A ports 1x USB 3.2 Gen2 Type C ports 1x USB 3.2 Gen 2x2 Type C ports V-check point TPM (Trusted Platform Module ) 1x TPM pin header(Support TPM 2.0) Warranty Information Manufacturing Warranty 3 Years MSI MEG X670E GODLIKE DDR5 AMD AM5 E-ATX Motherboard The AMD Ryzen 7000-series processors with up to 16 Zen 4 cores and dual-channel DDR5 RAM with a maximum Memory Capacity of up to 128GB are supported by the MSI MEG X670E GODLIKE Motherboard. The MEG X670E GODLIKE is made with a black, massive heatsink that features a dark mirror and a time-carving design in pale gold lighting to depict perfection in its purest form and to reflect timelessness in form and function. High-speed transmission, extreme performance, and the industry's first M-Vision Dashboard are all included. The Touchable 4.5-inch Full Color IPS LCD provides for touch control of system operation and customization in addition to providing status information about your gaming setup, combining hardware monitor and debug capability. With a 24+2+1 phase power design, a 105A Smart Power Stage, and two CPU power connectors, the MSI MEG X670E GODLIKE is equipped to deliver the highest level of performance. For the best performance at low temperatures, it has a wavy fin design, Direct Touch Cross Heat-pipe, MOSFET Baseplate, 7W/mK thermal pads, Double-Sided M.2 Shield Frozr, and Frozr AI software. The motherboard is constructed from a 10 Layer PCB with 2 oz Thickened Copper, which provides improved performance and unwavering system stability. The M.2 XPANDER-Z GEN5 DUAL PCI-Express card aboard the MSI MEG X670E GODLIKE Motherboard offers completely sextuple M.2 ports for optimal storage performance. With PCIe 5.0 slots, Lightning Gen 5 x4 M.2, Front USB 3.2 Gen 2x2 20G, and 60W USB Power Delivery, it can provide a lightning-fast gaming experience. The double-sided Shield Frozr architecture makes M.2 SSDs quicker while keeping them safe and reducing throttling. The rear I/O panel now provides quick access to Turbo mode, a one-click toggle for all RGB lights, and direct safe boot entry. The M.2 XPANDER-Z GEN5 DUAL PCI-Express card onboard and exclusive to the MSI MEG X670E GODLIKE delivers entirely sextuple M.2 ports for optimal storage performance. The double-sided Shield Frozr architecture makes M.2 SSDs quicker while keeping them safe and reducing throttling. There is a 3-year warranty included with the MSI MEG X670E GODLIKE Motherboard. ..
