Status
In Stock
9 listings tracked
Lowest Deal
23,500
Best Deal
Price Range
23,500 to 24,500
Save 4%
Product Description
Engineered by MSI, this motherboard is designed for **AM5** socket processors, featuring a **ATX** form factor, and supporting high-speed **DDR5** memory, providing a reliable foundation for custom desktop systems. Currently, the lowest price in Bangladesh for this item is **23,500 ৳**, with active inventory listings tracked from Star Tech, TechLand BD, PCB Store and other retailers.
Part ID: #CAN-01059
Last Updated: 2 days ago
Available Deals & Price Comparison
Prices updated daily| Retailer | Stock Status | Price | Last Checked | Action |
|---|---|---|---|---|
|
Ultra Technology
MSI B840 GAMING PLUS WIFI ATX Motherboard
|
In Stock | 23,500 | 3 hours ago | |
|
Star Tech
MSI B840 GAMING PLUS WIFI AMD AM5 ATX Motherboard
|
In Stock | 23,600 | 4 hours ago | |
|
TechLand BD
MSI B840 GAMING PLUS WIFI AM5 ATX AMD Motherboard
|
In Stock | 23,600 | 4 hours ago | |
|
Sell Tech
MSI B840 GAMING PLUS WIFI AMD AM5 ATX Motherboard
|
In Stock | 23,600 | 4 hours ago | |
|
Skyland BD
MSI B840 GAMING PLUS WIFI AMD AM5 ATX Motherboard
|
In Stock | 23,600 | 3 hours ago | |
|
Creatus Computer
MSI B840 GAMING PLUS WIFI AMD AM5 ATX Motherboard
|
In Stock | 23,900 | 4 hours ago | |
|
Nexus Computer
MSI B840 GAMING PLUS WIFI AMD AM5 ATX Motherboard
|
In Stock | 24,000 | 3 hours ago | |
|
UCC
MSI B840 GAMING PLUS WIFI AM5 DDR5 ATX Motherboard
|
In Stock | 24,500 | 4 hours ago | |
|
PCB Store
MSI B840 GAMING PLUS WIFI AM5 ATX Motherboard
|
Check Stock | 23,500 | 4 hours ago |
Historical Pricing Trend
Product Specifications
Basic Information
Supported CPU
Supports AMD Ryzen 9000/ 8000/ 7000 Series Desktop Processors Socket AM5
Chipset
AMD B840
Form Factor
ATX 243.84mmx304.8mm
Audio
Realtek ALC897 7.1-Channel High Definition Audio
Expansion Slots
PCI
5x PCI-E x16 slot PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E4 Gen PCIe 3.0 supports up to x4 (From Chipset) PCI_E5 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E1 slot • Supports PCIe 4.0 x16 (For Ryzen™ 9000/ 7000 Series processors) • Supports PCIe 4.0 x8 (For Ryzen™ 8700/ 8600/ 8400 Series processors) • Supports PCIe 4.0 x4 (For Ryzen™ 8500/ 8300 Series processor)
M.2 Socket
2x M.2 M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260 devices M2_2 slot • Supports up to PCIe 4.0 x4 (For Ryzen™ 9000/ 7000 Series processors) • Supports up to PCIe 3.0 x4 (For Ryzen™ 8700/ 8600/ 8400 Series processors) • Supports up to PCIe 3.0 x2 (For Ryzen™ 8500/ 8300 Series processor)
Memory
Type
DDR5
Slots
4x DDR5 UDIMM
Supported Memory
Memory Support DDR5 8000 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/s Ryzen™ 9000 Series Processors max. overclocking frequency: • 1DPC 1R Max speed up to 8000+ MT/s • 1DPC 2R Max speed up to 6400+ MT/s • 2DPC 1R Max speed up to 6400+ MT/s • 2DPC 2R Max speed up to 4800+ MT/s Supports AMD POR Speed and JEDEC Speed Supports Memory Overclocking and AMD EXPOTM Supports Dual-Channel mode Supports Non-ECC, Un-buffered memory Supports CUDIMM, Clock Driver bypass mode only*
Maximum Memory
256GB
Connector & Ports
HDMI
1x HDMI
USB (s)
4x USB 2.0 (Rear) 4x USB 2.0 (Front) 2x USB 5Gbps Type A (Rear) 2x USB 5Gbps Type A (Front) 1x USB 5Gbps Type C (Front) 1x USB 10Gbps Type A (Rear) 1x USB 10Gbps Type C (Rear)
LAN Port (s)
Realtek® 8125BG 2.5G LAN
Wireless Communication module
Wi-Fi 7 Solution The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz* (320MHz) up to 5.8Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax/ be Supports Bluetooth 5.4**, MLO, 4KQAM
Supported Storage
2x M.2 M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260 devices 4x SATA 6G M2_2 slot • Supports up to PCIe 4.0 x4 (For Ryzen™ 9000/ 7000 Series processors) • Supports up to PCIe 3.0 x4 (For Ryzen™ 8700/ 8600/ 8400 Series processors) • Supports up to PCIe 3.0 x2 (For Ryzen™ 8500/ 8300 Series processor)
RAID
Supports RAID 0 and RAID 1 for M.2 NVMe storage devices
Internal I/O Ports
1x Power Connector(ATX_PWR) 1x Power Connector(CPU_PWR) 1x CPU Fan 1x Combo Fan (Pump_Sys Fan) 4x System Fan 1x EZ Conn-header (JAF_1) 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM) 1x Tuning Controller connector(JDASH) 2x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 5Gbps Type A ports 1x USB 5Gbps Type C ports
Warranty Information
Manufacturing Warranty
3 Years
Key Features
Model
B840 GAMING PLUS WIFI
Supported CPU
AMD Ryzen 9000/ 8000/ 7000 Series for Socket AM5
Supported RAM
4x DDR5, Dual Channel DDR5 8000+ MT/s (OC), Max 256GB
Graphics Output
1x HDMI 2.1, maximum resolution of 4K 60Hz
Features
2x M.2 Slot, Realtek 8125BG 2.5G LAN, Wi-Fi 7
Part ID: #CAN-01059
Last Updated: 2 days ago
The MSI B840 Gaming Plus WiFi Motherboard supports AMD Ryzen 9000, 8000, and 7000 Series desktop processors. It is perfect for demanding multitasking and gaming settings because it supports DDR5 memory in dual-channel mode and can overclock to achieve speeds of up to 8000+ MT/s. With a sturdy 7+2+1 phase power supply system, core and memory boost technologies, and a 6-layer PCB with thickened copper for reliable performance, the MSI B840 Gaming Plus WiFi AMD AM5 ATX Motherboard is designed for efficiency. This MSI DDR5 motherboard's enhanced cooling is guaranteed for continuous use with the Frozr Guard, extended heatsinks, thermal pads, and EZ M.2 Shield Frozr II. With Wi-Fi 7 providing lightning-fast speeds of up to 5.8Gbps, 2.5G LAN for dependable networking, and numerous USB ports, including USB 10Gbps Type-C and Type-A options for quick data transfers, the connectivity options are excellent. Two M.2 slots with RAID capabilities, four SATA 6G ports for flexible storage configurations, and PCIe 4.0 support for graphics cards and storage are all features of the MSI B840 Gaming Plus WiFi AM5 ATX Motherboard. A 7.1-channel immersive experience is guaranteed with this MSI AM5 Motherboard's improved audio powered by Realtek ALC897. Support for 4K resolutions is made possible via onboard HDMI 2.1 and DisplayPort 1.4, meeting demands for entertainment and business. EZ PCIe and M.2 Clips are two features of the MSI B840 Gaming Plus WiFi AMD AM5 ATX Motherboard EZ DIY that simplify upgrades and installation. Addressable V2 RGB LED and RGB LED connectors allow RGB lovers to take advantage of the customizable lighting possibilities. The ATX form factor, which was created for Windows 11 64-bit PCs, provides plenty of room and compatibility for complex configurations. Building a high-end gaming or productivity setup is made easy with the MSI B840 Gaming Plus WiFi motherboard, which offers outstanding performance and connection along with sophisticated security features like TPM 2.0 compatibility and a wide range of internal I/O options.Buy MSI B840 GAMING PLUS WIFI AMD AM5 ATX Motherboard from Star TechIn Bangladesh, you can get original MSI B840 GAMING PLUS WIFI AMD AM5 ATX Motherboard From Star Tech. We have a large collection of latest MSI Motherboard to purchase for your Desktop PC. Order Online Or Visit your Nearest Star Tech Shop to get yours at lowest price. The MSI B840 GAMING PLUS WIFI AMD AM5 ATX Motherboard comes with 3 years warranty.
