Unleash Your Gaming Potential with the Gigabyte Z390 AORUS XTREME
Designed for extreme overclockers and gamers, the Gigabyte Z390 AORUS XTREME motherboard offers unparalleled performance, cutting-edge features, and advanced cooling solutions to deliver an unparalleled gaming experience. Whether you're a pro gamer or an enthusiast, this motherboard is the perfect choice to take your gaming to the next level.
Key Features and Benefits
- Supports 9th and 8th Generation Intel Core processors for exceptional performance and power efficiency
- Quad-channel DDR4 memory, supporting up to 128GB of system memory for seamless multitasking
- Integrated Intel Thunderbolt 3 technology, offering speeds of up to 40 Gbps and 4K display support
- Advanced cooling solutions, including a robust heatsink and thermal design for optimal temperatures
- Support for 3D audio and high-definition audio, delivering immersive sound and an enhanced gaming experience
Exclusive Technologies and Features
The Gigabyte Z390 AORUS XTREME motherboard boasts several exclusive technologies and features, including:
APP Center
APP Center is a suite of applications that provides users with a range of tools and features to optimize their system performance, monitor system health, and customize their gaming experience.
OC Touch Panel
The OC Touch Panel is a proprietary feature that allows users to monitor and adjust their system settings, including CPU frequency, memory frequency, and fan settings, in real-time.
Smart Fan
The Smart Fan feature is designed to optimize system cooling by automatically adjusting fan speeds based on system temperature and workload.
Part ID: #CAN-02033
Last Updated: 1 month ago
Available Deals & Price Comparison
Prices updated daily| Retailer | Stock Status | Price | Last Checked | Action |
|---|---|---|---|---|
|
Creatus Computer
Gigabyte Z390 AORUS XTREME 9th Gen Motherboard
|
Check Stock | Call for Price | 4 hours ago | |
|
Creatus Computer
Gigabyte Z390 AORUS XTREME 9th Gen Motherboard
|
Check Stock | Call for Price | 4 hours ago | |
|
Creatus Computer
Gigabyte Z390 Aorus Xtreme Waterforce Motherboard
|
Check Stock | Call for Price | 4 hours ago | |
|
Nexus Computer
Gigabyte Z390 AORUS XTREME 9th Gen Motherboard
|
Check Stock | 50,000 | 4 hours ago | |
|
PC House
GIGABYTE Z390 AORUS XTREME GAMING MOTHERBOARD
|
Check Stock | 51,000 | 1 month ago |
Historical Pricing Trend
Product Specifications
Basic Information
Supported CPU
Support for 9th and 8th Generation Intel® Core™ i9 processors/ Intel® Core™ i7 processors/ Intel® Core™ i5 processors/ Intel® Core™ i3 processors/ Intel® Pentium® processors/ Intel® Celeron® processors in the LGA1151 package L3 cache varies with CPU
Chipset
Intel® Z390 Express Chipset
BIOS
2 x 128 Mbit flash Use of licensed AMI UEFI BIOS Support for DualBIOS™ Support for Q-Flash Plus * The USB flash drive used must be a USB 2.0 flash drive. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form Factor
E-ATX Form Factor; 30.5cm x 27.1cm
Audio
5 x audio jacks
Expansion Slots
PCI
1 x PCI Express x16 slot, running at x16 (PCIEX16) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. 1 x PCI Express x16 slot, running at x8 (PCIEX8) * The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot is populated, the PCIEX16 slot operates at up to x8 mode. 1 x PCI Express x16 slot, running at x4 (PCIEX4) * The PCIEX4 slot shares bandwidth with the M2P connector. The PCIEX4 slot operates at up to x2 mode when a PCIe SSD is installed in the M2P connector. (All of the PCI Express x16 slots conform to PCI Express 3.0 standard.) 2 x PCI Express x1 slots (All of the PCI Express x1 slots conform to PCI Express 2.0 standard.)
M.2 Socket
1 x M.2 Socket 1 connector for an Intel CNVi wireless module only (CNVI)
Memory
Type
4 x DDR4 DIMM sockets supporting up to 128GB (32GB single DIMM capacity) of system memory Please note that the support for system total memory size depends on the CPU installed.
Slots
Dual channel memory architecture
Supported Memory
Support for DDR4 4400(O.C.) / 4333(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2800(O.C.) / 2666 / 2400 / 2133 MHz memory modules Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules
Maximum Mamory
128 GB
Graphics
Graphics
Integrated Graphics Processor+Intel Thunderbolt 3 Controller: 2 x Intel Thunderbolt 3 connectors (USB Type-C ports), supporting DisplayPort and Thunderbolt video outputs and a maximum resolution of 4096x2304@60 Hz Because of the limited I/O resources of the PC architecture, the number of Thunderbolt devices that can be used is dependent on the number of the PCI Express devices being installed. (Refer to Chapter 1-7, "Back Panel Connectors," for more information.) Support for DisplayPort 1.2 version. Integrated Graphics Processor-Intel® HD Graphics support: 1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz Support for HDMI 1.4 version and HDCP 2.2.
Max Shared Memory
1 GB
Connector & Ports
HDMI
1 x HDMI port
USB (s)
Chipset+Intel Thunderbolt 3 Controller: 2 x USB Type-C ports on the back panel, with USB 3.1 Gen 2 support Chipset: 1 x USB Type-C port with USB 3.1 Gen 2 support, available through the internal USB header 4 x USB 3.1 Gen 2 Type-A ports (red) on the back panel 4 x USB 3.1 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header) Chipset+2 USB 2.0 Hubs: 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)
LAN Port (s)
2 x RJ-45 ports (1 x Aquantia GbE LAN chip (10 Gbit/5 Gbit/2.5 Gbit/1000 Mbit/100 Mbit) (LAN1)) (1 x Intel GbE LAN phy (10/100/1000 Mbit) (LAN2))
Supported Storage
1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2 SSD support) (M2M) 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 SATA and PCIe x4/x2 SSD support) (M2A) 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 PCIe x4/x2 SSD support) (M2P) 6 x SATA 6Gb/s connectors Support for RAID 0, RAID 1, RAID 5, and RAID 10 * Refer to "1-10 Internal Connectors," for the installation notices for the PCIEX4, M.2, and SATA connectors. Intel Optane Memory Ready
Audio
Realtek ALC1220-VB codec ESS ES9018K2M DAC and TI OPA1622 operational amplifiers The front panel line out jack supports DSD audio. High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out
Internal I/O Ports
1 x 24-pin ATX main power connector 2 x 8-pin ATX 12V power connectors 1 x OC PEG power connector 1 x CPU fan header 1 x water cooling CPU fan header 4 x system fan headers 2 x system fan/water cooling pump headers 2 x addressable LED strip headers 2 x addressable LED strip power select jumpers 2 x RGB LED strip headers 6 x SATA 6Gb/s connectors 3 x M.2 Socket 3 connectors 1 x front panel header 1 x front panel audio header 1 x USB Type-C™ port, with USB 3.1 Gen 2 support 1 x USB 3.1 Gen 1 header 2 x USB 2.0/1.1 headers 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only) 1 x GC-OC Touch add-in card connector 1 x Clear CMOS jumper 2 x temperature sensor headers 1 x power button 1 x reset button 1 x Clear CMOS button 1 x OC button 2 x BIOS switches
Warranty Information
Manufacturing Warranty
03 Years
Others
Special Features
Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. 3D OSD @BIOS AutoGreen Cloud Station EasyTune Easy RAID Fast Boot Game Boost Platform Power Management RGB Fusion Smart Backup Smart Keyboard Smart TimeLock Smart HUD Smart Survey System Information Viewer USB Blocker USB TurboCharger Smart Fan (for AORUS RGB FAN COMMANDER ) Support for Q-Flash Support for Xpress Install
Bundled Software
Norton® Internet Security (OEM version) cFosSpeed XSplit Gamecaster + Broadcaster (12 months license)
