Product Description
Engineered by Gigabyte, this motherboard is supporting high-speed **DDR5** memory, providing a reliable foundation for custom desktop systems. Currently, the lowest price in Bangladesh for this item is **17,000 ৳**, with active inventory listings tracked from TechLand BD, Ultra Technology.
Part ID: #CAN-01443
Last Updated: 2 days ago
Available Deals & Price Comparison
Prices updated dailyHistorical Pricing Trend
Product Specifications
General Specifications
OS
Support for Windows 11 64-bitSupport for Windows 10 64-bit
LAN
Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
USB
Chipset:- 5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header)- 3 x USB 2.0/1.1 ports on the back panelChipset+USB 2.0 Hub:- 4 x USB 2.0/1.1 ports available through the internal USB headers
BIOS
1 x 256 Mbit flashUse of licensed AMI UEFI BIOSPnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Audio
Realtek Audio CODECHigh Definition Audio2/4/5.1/7.1-channel
Slots
CPU:- 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16)* The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot.Chipset:- 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4)
Memory
Support for DDR5 9066(O.C) / 8800(O.C) / 8600(O.C) / 8400(O.C) / 8266(O.C) / 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400 / 5600 MT/s memory modules2 x DDR5 DIMM sockets supporting up to 128 GB (64 GB single DIMM capacity) of system memoryDual channel memory architectureSupport for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modulesSupport for Extreme Memory Profile (XMP) memory modules
Chipset
Intel B860 Express Chipset
Graphics
Integrated Graphics Processor-Intel HD Graphics support:- 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz* Support for DisplayPort 2.1 version.- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz* Support for HDMI 2.1 version and HDCP 2.3.
Warranty
3 Years
Form Factor
Micro ATX Form Factor; 24.4cm x 22.5cm
Supported CPU
LGA1851 socket: Support for Intel Core Ultra Processors
Special Features
Support for GIGABYTE Control Center (GCC)Support for Q-FlashSupport for Q-Flash PlusSupport for Smart Backup
Software Features
Voltage detectionTemperature detectionFan speed detectionWater cooling flow rate detectionFan fail warningFan speed control
Supported Storage
CPU:- 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU)Chipset:- 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB)- 4 x SATA 6Gb/s connectorsRAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices
External I/O Ports
3 x USB 2.0/1.1 ports1 x PS/2 keyboard/mouse port1 x DisplayPort*1 x HDMI port*3 x USB 3.2 Gen 1 ports1 x RJ-45 port3 x audio jacks
Internal I/O Ports
1 x 24-pin ATX main power connector1 x 8-pin ATX 12V power connector1 x CPU fan header1 x CPU fan/water cooling pump header1 x system fan header3 x addressable RGB Gen2 LED strip headers2 x M.2 Socket 3 connectors4 x SATA 6Gb/s connectors1 x front panel header1 x front panel audio header1 x S/PDIF Out header1 x USB 3.2 Gen 1 header2 x USB 2.0/1.1 headers1 x Trusted Platform Module header (For the GC-TPM2.0 SPI V2 module only)1 x serial port header1 x Q-Flash Plus button1 x reset jumper1 x Clear CMOS jumper
Part ID: #CAN-01443
Last Updated: 2 days ago
Gigabyte B860M D2H DDR5 MotherboardGigabyte B860M D2H DDR5 is a feature-rich Micro-ATX motherboard designed for Intel Core Ultra processors, delivering next-generation performance, stable power delivery, and modern connectivity for both gamers and professionals.Processor & Chipset SupportPowered by the Intel B860 Express Chipset, this motherboard supports the latest Intel® Core™ Ultra processors on the LGA1851 socket. It ensures efficient performance, optimized power management, and compatibility with Intel’s newest platform technologies, making it ideal for modern PC builds.Memory PerformanceThe board supports DDR5 memory up to 9066 MT/s (OC) with dual-channel architecture and a maximum capacity of 128GB across two DIMM slots. With support for XMP profiles and both ECC (non-ECC mode) and non-ECC unbuffered memory, users can enjoy high-speed multitasking, improved bandwidth, and system stability.Graphics & Display OutputIntegrated Intel HD Graphics support allows smooth visual performance with DisplayPort 2.1 supporting up to 4K @144Hz and HDMI 2.1 supporting 4K @60Hz. This makes it suitable for productivity setups, high-resolution monitors, and media consumption without a dedicated GPU.Expansion & Storage OptionsFor expansion, the motherboard features a PCIe 5.0 x16 slot for next-gen graphics cards and a PCIe 4.0 x4 slot for additional devices. Storage options include two PCIe 4.0 M.2 slots for fast NVMe SSDs and four SATA 6Gb/s ports with RAID 0/1/5/10 support, ensuring flexible and high-speed storage configurations.Connectivity & AudioNetworking is handled by a Realtek 2.5GbE LAN, delivering fast and stable wired internet. Audio is powered by a Realtek High Definition Audio codec with support for 7.1-channel surround sound and S/PDIF Out, providing immersive sound quality for gaming and entertainment.Cooling, BIOS & FeaturesThe board includes smart fan headers, water-cooling support, and advanced hardware monitoring. Q-Flash Plus allows BIOS updates without a CPU, while GIGABYTE Control Center offers easy system tuning and management. Support for Windows 11 ensures full compatibility with Intel NPU features.Buy Now – Gigabyte B860M D2H DDR5 Motherboard Form Ultra TechnologyUpgrade your PC with the Gigabyte B860M D2H DDR5 LGA1851 Socket Motherboard from Ultra Technology and enjoy next-generation performance, stability, and long-term reliability in a compact Micro-ATX form factor...
