VOID SPLIT Shards of the Void; Borders Disappear Fusing different materials and surface textures with negative space to form a juxtaposition and showcase a stylistic effect where the boundaries between components are not clearly defined. It creates a multi-dimensional design that seemingly cuts through space and time. Intel® WiFi 6 802.11ax 2T2R & BT5 DisplayPort Onboard HDMI USB 3.2 Gen2 Type-C Q-Flash Plus USB Port Intel® 2.5GbE LAN Advanced Thermal Design Enlarged Heatsink 5 W/mK LAIRD Thermal Conductivity Pad 2* M.2 Connectors with Thermal Guards NVMe PCIe Gen3 X4 & X2 M.2 Slots AMP-UP Audio ALC1220-VB Audio Codec Audio Noise Guard High-End Audio Capacitor Audiophile Grade WIMA & Nichicon MW Capacitors RGB FUSION 2.0 Addressable LED Header*2 RGB LED Header*2 Dual Channel DDR4, 4 DIMMs Supports 10th Gen. Intel® Core™ Processors Solid Pin Power Connectors 24 pin ATX Power Connector 8 pin CPU Power Connector Direct 8+2 Phases Digital VRM Solution Premium Choke and Capacitor Ultra Durable PCIe Armor Running 1 x16 Q-FLASH Onboard Button DIRECT POWER DESIGN Direct 8+2 Phases Digital VRM Solution with Low RDS(on) MOSFET B460 AORUS PRO AC motherboard use a 8+2 phase digital PWM + Lower RDS(on) MOSFETs design to support the latest 10-core Intel® Core™ CPUs by offering incredible precision in delivering power to the motherboard’s most power-hungry and energy-sensitive components as well as delivering enhanced system performance and ultimate hardware scalability. Benefits of Lower RDS(on) MOSFETs Optimized gate charge to minimize switching losses. Lower temperature, smaller size, better thermal characteristics. Direct Power Phase Design AORUS PERFORMANCE With the best quality components and GIGABYTE R&D design capability, the B460 AORUS is a true beast among motherboards. Single 32GB Support The maximum memory capacity on the B460 motherboard is 128GB. After Intel updated the memory reference code, a single slot can support up to 32GB. Therefore with populated 2 DIMM per channel on both channel, total memory capacity is 128GB, which was only available on High End Desktop (HEDT) platforms. For users who always run out of memory capacity, there is more bandwidth now for memory-intensive application such as rendering and video editing. Dual NVMe PCIe Gen3 M.2 Slots (x4,x2) GIGABYTE Motherboards are focused on delivering M.2 technology to enthusiasts who want to maximize their system’s potential. Durable design and easy installation With an integrated base plate, GIGABYTE Motherboards give users a strong foundation to build their Gaming PCs. With an integrated I/O shield, building a GIGABYTE Ultra Durable PC is even easier. ADVANCED THERMAL SOLUTION Enlarged MOSFET Heatsinks 5 W/mK LAIRD Thermal Conductivity Pad 2X M.2 Thermal Guards AORUS M.2 Thermal Guard GIGABYTE Ultra-Efficient M.2 Thermal Guard With durability in mind, GIGABYTE provides a thermal solution for M.2 SSD devices. The M.2 Thermal Guard prevents throttling and bottlenecks from high speed M.2 SSDs as it helps to dissipate heat before it becomes an issue. Thermal Throttling As Temperature Rises rt Fan 5 With Smart Fan 5 users can ensure that their gaming PC can maintain its performance while staying cool. Smart Fan 5 allows users to interchange their fan headers to reflect different thermal sensors at different locations on the motherboard. Not only that, with Smart Fan 5 more hybrid fan headers that support both PWM and Voltage mode fans have been introduced to make the motherboard more liquid cooling friendly. Fan / Water Pump Connectors Internal Temperature Sensors Temperature Sensors Hybrid Fan Headers ■ 5 Fan / Water Pump Connectors ■ 6 Temperature Sensors ■ All Fan Pin Headers Upgraded to Hybrid Fan Headers ■ Interoperable Fans and Sensors ■ Intuitive UI for Fan Control * Different models have a different number of fan pin headers and temperature sensors. Smart Fan 5 function may vary by model. Hybrid Fan Pin Headers Assume complete control over your liquid cooling setup! Smart Fan 5 receives up-to-the-second information on flow-rate through the Hybrid Fan Pin Headers—giving you absolute mastery over your PC. All Hybrid Fan Headers can automatically detect the type of cooling device whether it be fan or pump with different PWM or Voltage mode. New Smart Fan 5 Software Choose from different modes, Quiet to Full Speed, to match your system usage preferences. For each fan or pump, you can use the intuitive fan curve to define trigger thresholds and corresponding fan speeds. NEXT GENERATION CONNECTIVITY Intel 2.5GbE LAN Onboard   2X Faster than ever Adoption of 2.5G LAN provide up to 2.5 GbE network connectivity, with at least two times faster transfer speeds compared to general 1GbE networking. It’s perfectly suit for gamers and streamer with ultimate and smooth online experience. It also backward compatible with Multi-Gig(10/100/1000/2500Mbps) RJ-45 ethernet.   Smashes the GbE Barrier! Integrated Intel® 802.11ac Wave2 CNVi WIFI + Bluetooth 5 Intel Next-Gen Wireless solution supports 802.11ac Wave 2 function, enables gigabit wireless performance, provides smooth video streaming, better gaming experience, few dropped connections and speeds up to 1.73Gbps. Double the speed compared to the previous generation. Moreover, Bluetooth 5 provides 4x range over BT4.2 and with faster transmission. Intel’s native USB 3.2 Gen2 host controller provides USB 3.2 Gen2 ports with speeds up to 10Gbps .With twice the bandwidth compared to its previous generation as well as backwards compatibility with USB 2.0 and USB 3.2 Gen1 , the much improved USB 3.2 Gen2 protocol is available over the new reversible USB Type-C™ and the traditional USB Type-A connector for better compatibility over a wider range of devices. AORUS AUDIO1220 120dB SNR HD Audio The ALC1220 is a high-performance multi-channel High Definition Audio Codec with up to 120dB SNR for crystal clear audio and features such as Smart Headphone Amp, 114dB SNR recording for precise voice chats and hardware decoding of DSD128, ensuring users get the best possible audio quality from their PC. Smart Headphone Amp Automatically detects impedance of your head-worn audio device, whether earbuds or high-end headphones to provide optimal audio dynamics—preventing issues such as low volume and distortion. High-End WIMA & Audio Capacitors The AORUS motherboards boast a combination of Hi-Fi grade WIMA FKP2 capacitors and high-end Nichicon audio capacitors. While the high-end audio capacitors are suited for high-grade audio equipment, using state of the art technology to provide rich sound in the bass and clearer high frequencies, the WIMA FKP2 capacitors are being used widely in premium grade Hi-Fi systems. The addition of this to the exclusive AOURS AMP-UP Audio technology makes for the ideal onboard sound solution for the most demanding audiophiles. AORUS STYLE Now offering more LED customizations than ever, users can truly adapt their PC to represent their lifestyle. With full RGB support and a redesigned RGB Fusion 2.0 application, the user has complete control over the LEDs which surround the motherboard.   With an integrated intuitive user interface, the RGB Fusion 2.0 provides you a better solution for customizing the lighting effects across all supported devices. From motherboards, graphics cards to the peripheral products, you can personalize your gaming rig with your own style and show off your build by sharing the profiles. In addition, the new gaming mode makes the lighting effects interactive with selected games to bring you the most immersive gaming experience.   ULTRA DURABLE GIGABYTE is reputable for its product durability and high quality manufacturing process. Needless to say, we use the best components we can find for the B460 AORUS motherboard and reinforce every slot to make each of them solid and durable. PCIe Armor Patented Double Locking Bracket Solid Pin Q-Flash Plus GIGABYTE BIOS & APP CENTER Good software goes hand in hand with perfect hardware. B460 AORUS PRO AC bundled several useful and intuitive software to help users to control every aspect of motherboard. BIOS APP Center Easy Tune System Information Viewer * Product specifications and product appearance may differ from country to country. We recommend that you check with your local dealers for the specifications and appearance of the products available in your country. Colors of products may not be perfectly accurate due to variations caused by photographic variables and monitor settings so it may vary from images shown on this site. Although we endeavor to present the most accurate and comprehensive information at the time of publication, we reserve the right to make changes without prior notice.
