Product Description
Unleash Unparalleled Performance with the ASUS TUF H770-PRO WIFI Motherboard
Designed for extreme gaming and content creation, the ASUS TUF H770-PRO WIFI motherboard is the ultimate choice for PC enthusiasts who demand uncompromising performance and reliability. With its cutting-edge Intel H770 chipset and support for 14th, 13th Gen Intel Core Processors, this motherboard is built to deliver exceptional speeds and efficiency.
Key Features
Technical Specifications:
- Supports Intel Socket LGA1700 for 14th, 13th Gen Intel Core Processors & 12th Gen Intel Core, Pentium Gold and Celeron Processors
- 1 x PCIe 5.0 x16 slot and 1 x PCIe 4.0 x16 slot for seamless expansion
- 4 x M.2 slots and 4 x SATA 6Gb/s ports for ample storage options
- Intel 2.5Gb Ethernet and Wi-Fi 6 for lightning-fast networking
- Realtek 7.1 Surround Sound High Definition Audio CODEC for immersive audio
- DDR5 memory support with speeds up to 7200(OC)/ 7000(OC)/ 6800(OC)
ASUS TUF PROTECTION and Thermal Solution
Industry-Leading Technologies:
The ASUS TUF H770-PRO WIFI motherboard boasts an array of proprietary technologies designed to enhance performance, reliability, and user experience. Key features include:
- DIGI+ VRM for digital power design and reduced noise
- ASUS Q-Design for intuitive and user-friendly interface
- ASUS TUF PROTECTION for comprehensive protection against power surges and electrical noise
- ASUS Thermal Solution for efficient heat dissipation and cooler operation
Part ID: #CAN-02173
Last Updated: 1 month ago
Available Deals & Price Comparison
Prices updated dailyHistorical Pricing Trend
Product Specifications
Basic Information
Supported CPU
Intel Socket LGA1700 for 14th, 13th Gen Intel Core Processors & 12th Gen Intel Core, Pentium Gold and Celeron Processors Supports Intel Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0
Chipset
Intel H770 Chipset
BIOS
192 (128+64) Mb Flash ROM, UEFI AMI BIOS
Form Factor
ATX Form Factor 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
Audio
5 x Audio jacks
Expansion Slots
PCI
Intel 13th & 12th Gen Processors 1 x PCIe 5.0 x16 slot Intel H770 Chipset 1 x PCIe 4.0 x16 slot (supports x4 mode) 2 x PCIe 3.0 x1 slots
Memory
Maximum Memory
192GB
Supported Memory
DDR5 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600/ 5400/ 5200/ 5000/ 4800 Non-ECC, Un-buffered Memory Dual Channel Memory Architecture Supports Intel® Extreme Memory Profile (XMP) OptiMem II
Type
DDR5
Graphics
Graphics
1 x DisplayPort 1 x HDMI port
Ports, Connectors & Slots
Audio
Realtek 7.1 Surround Sound High Definition Audio CODEC - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking - Supports up to 24-Bit/192 kHz playback Audio Features - Audio Shielding - Rear optical S/PDIF out port - Premium audio capacitors - Dedicated audio PCB layers - Audio Cover
HDMI/VGA
1 x HDMI
Internal I/O Ports
Fan and Cooling related 1 x 4-pin CPU Fan header 1 x 4-pin CPU OPT Fan header 1 x 4-pin AIO Pump header 4 x 4-pin Chassis Fan headers Power related 1 x 24-pin Main Power connector 1 x 8-pin +12V Power connector 1 x 4-pin +12V Power connector Storage related 4 x M.2 slots (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 3.2 Gen 1 connector (supports USB Type-C) 1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports 2 x USB 2.0 headers support additional 4 USB 2.0 ports Miscellaneous 3 x Addressable Gen 2 headers 1 x Aura RGB header 1 x Clear CMOS header 1 x COM Port header 1 x Front Panel Audio header (AAFP) 1 x 20-3 pin System Panel header with Chassis intrude function 1 x Thunderbolt (USB4) header
LAN Port (s)
1 x Intel 2.5Gb Ethernet TUF LANGuard
Supported Storage
Total supports 4 x M.2 slots and 4 x SATA 6Gb/s ports* Intel 13th & 12th Gen Processors M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4) Intel® H770 Chipset M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode) M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 & SATA modes) 4 x SATA 6Gb/s ports
TPM (Trusted Platform Module )
1 x SPI TPM header (14-1pin)
USB (s)
Rear USB (Total 7 ports) 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C) 2 x USB 3.2 Gen 2 ports (2 x Type-A) 4 x USB 3.2 Gen 1 ports (4 x Type-A) Front USB (Total 7 ports) 1 x USB 3.2 Gen 1 connector (supports USB Type-C) 1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports 2 x USB 2.0 headers support additional 4 USB 2.0 ports
Warranty
Manufacturing Warranty
3 years
Other Features
Special Features
ASUS TUF PROTECTION - DIGI+ VRM (- Digital power design with DrMOS) - ESD Guards - TUF LANGuard - Overvoltage Protection - Safeslot Core+ - Stainless-Steel Back I/O ASUS Q-Design - M.2 Q-Latch - Q-DIMM - Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) - Q-Slot ASUS Thermal Solution - M.2 heatsink - VRM heatsink design ASUS EZ DIY - CPU Socket lever protector - ProCool - Pre-mounted I/O shield - SafeSlot Core+ - SafeDIMM AURA Sync - Aura RGB header - Addressable Gen 2 headers
Part ID: #CAN-02173
Last Updated: 1 month ago
