Product Description
Engineered by ASUS, this motherboard is designed for **LGA1700** socket processors, featuring a **micro-ATX** form factor, and supporting high-speed **DDR5** memory, providing a reliable foundation for custom desktop systems. Currently, the lowest price in Bangladesh for this item is **11,300 ৳**, with active inventory listings tracked from Global Brand PLC, Ultra Technology.
Part ID: #CAN-01815
Last Updated: 2 days ago
Available Deals & Price Comparison
Prices updated dailyHistorical Pricing Trend
Product Specifications
General Specifications
CPU
Intel Socket LGA1700 for 13th Gen Intel Core & 12th Gen Intel Core, Pentium Gold and Celeron Processors* Supports up to Intel 65W CPU Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0** * Refer to www.asus.com for CPU support list. ** Intel Turbo Boost Max Technology 3.0 support depends on the CPU types.
USB
Rear USB (Total 6 ports) 2 x USB 3.2 Gen 1(5G) ports (2 x Type-A) 4 x USB 2.0 ports (4 x Type-A) Front USB (Total 4 ports) 1 x USB 3.2 Gen 1(5G) header supports additional 2 USB 3.2 Gen 1 ports 1 x USB 2.0 header supports additional 2 USB 2.0 ports
BIOS
128 Mb Flash ROM, UEFI AMI BIOS
Audio
Realtek 7.1 Surround Sound High Definition Audio CODEC* - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking - Supports up to 24-Bit/192 kHz playback Audio Features - Audio Shielding - Premium audio capacitors - Dedicated audio PCB layers * A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.
Model
PRIME H610M-CS
Memory
2 x DIMM, Max. 96GB, DDR5 5600/5400/5200/5000/4800 Non-ECC, Un-buffered Memory* Dual Channel Memory Architecture Supports Intel Extreme Memory Profile (XMP) * Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit https://www.asus.com/support/. * Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.
Chipset
Intel H610 Chipset
Storage
Total supports 1 x M.2 slot and 4 x SATA 6Gb/s ports Intel H610 Chipset M.2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 mode) 4 x SATA 6Gb/s ports
Ethernet
1 x Realtek 1Gb Ethernet
Graphics
1 x VGA port 1 x HDMI port** * Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates. ** Supports 4K@60Hz as specified in HDMI 2.1.
Warranty
3 Years Replacement Warranty *(Terms and Conditions Applied)
Accessories
Cables 2 x SATA 6Gb/s cables Miscellaneous 1 x I/O Shield 1 x M.2 ANCHOR Documentation 1 x User guide
Form Factor
mATX Form Factor 8.9 inch x 7.7 inch (22.6 cm x 19.5 cm)
Key Feature 1
Chipset: Intel H610 Chipset for 13th Gen & 12th Gen
Key Feature 2
Socket: Intel Socket LGA1700
Key Feature 3
Storage Supports: 1 x M.2 slot and 4 x SATA 6Gb/s ports
Key Feature 4
Memory: 2 x DIMM, Max. 96GB, DDR5
Key Feature 5
Features: PCH heatsink, PCIe 4.0, 5X Protection III
Manageability
WOL by PME, PXE
Expansion Slots
Intel 13th & 12th Gen Processors 1 x PCIe 4.0 x16 slot Intel H610 Chipset 1 x PCIe 3.0 x1 slot - To ensure compatibility of the device installed, please refer to https://www.asus.com/support/ for the list of supported peripherals.
Operating System
Windows 11, Windows 10 64-bit
Special Features
ASUS 5X PROTECTION III - DIGI+ VRM - LANGuard - Overvoltage Protection - SafeSlot Core - Stainless-Steel Back I/O ASUS Q-Design - Q-DIMM - Q-Slot - Q-LED Core ASUS Thermal Solution - Aluminum heatsink design USBGuard
Software Features
ASUS Exclusive Software Armoury Crate AI Suite 3 EPU DIGI+ VRM PC Cleaner ASUS CPU-Z Norton 360 for Deluxe (60 Days Free Trial) WinRAR UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode
Internal I/O Ports
Fan and Cooling related 1 x 4-pin CPU Fan header 1 x 4-pin Chassis Fan header Power related 1 x 24-pin Main Power connector 1 x 4-pin +12V Power connector Storage related 1 x M.2 slot (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 3.2 Gen 1(5G) header supports additional 2 USB 3.2 Gen 1 ports 1 x USB 2.0 header supports an additional 2 USB 2.0 ports Miscellaneous 1 x Clear CMOS header 1 x Chassis Intrusion header 1 x COM Port header 1 x Front Panel Audio header (AAFP) 1 x LPT header 1 x Speaker header 1 x SPI TPM header (14-1 pin) 1 x 10-1 pin System Panel header
Back Panel I/O Ports
2 x USB 3.2 Gen 1(5G) ports (2 x Type-A) 4 x USB 2.0 ports (4 x Type-A) 1 x VGA port 1 x HDMI port 1 x Realtek 1Gb Ethernet port 3 x Audio jacks 1 x PS/2 Keyboard (purple) port 1 x PS/2 Mouse (green) port
Part ID: #CAN-01815
Last Updated: 2 days ago
The ASUS PRIME H610M-CS LGA1700 is a feature-rich micro-ATX motherboard designed to support 12th and 13th Generation Intel Core, Pentium Gold, and Celeron processors. Built on the Intel H610 chipset, this motherboard offers solid performance and reliability, making it ideal for both home and office use. It supports up to 96GB of DDR5 memory with speeds up to 5600MHz, ensuring high-speed data processing and multitasking capabilities. The dual-channel memory architecture and Intel XMP support further enhance memory performance. For graphics, the motherboard provides both VGA and HDMI ports, with the HDMI port supporting 4K resolution at 60Hz, offering crystal-clear visuals for modern displays. The expansion slots include a PCIe 4.0 x16 slot for high-speed graphics cards and a PCIe 3.0 x1 slot for additional peripherals. Storage options are versatile, with one M.2 slot supporting PCIe 3.0 x4 mode and four SATA 6Gb/s ports, allowing for fast data transfer rates and ample storage solutions. The Realtek 1Gb Ethernet ensures reliable network connectivity, while the Realtek 7.1 Surround Sound Audio CODEC delivers high-definition audio for an immersive multimedia experience. ASUS PRIME H610M-CS also features several ASUS-exclusive technologies like 5X Protection III, ensuring long-term durability and stability with protections such as overvoltage protection, SafeSlot Core, and stainless-steel back I/O. Additionally, it offers a range of connectivity options, including USB 3.2 Gen 1 and USB 2.0 ports, both on the front and rear panels. The motherboard includes comprehensive software, such as Armoury Crate and AI Suite 3, which help manage system performance and keep everything running smoothly. With a compact form factor and a 3-year warranty, this motherboard offers great value for users looking to build a reliable and efficient PC...
