Product Description
Unleash Unparalleled Performance with the ASUS PRIME H310M-AT R2.0
This motherboard is designed for the discerning builder who demands uncompromising performance, reliability, and aesthetics. Engineered to deliver exceptional performance, this ASUS motherboard is the perfect choice for PC enthusiasts and professionals.
Technical Specifications and Features
Key Features:
- 9th and 8th Gen Intel Core Support: Compatible with Intel Socket 1151 processors, ensuring seamless integration with your CPU of choice.
- PCIe 3.0 and 2.0 Expansion: With one PCIe 3.0/2.0 x16 slot and two PCIe 2.0 x1 slots, you'll have ample room for graphics cards, sound cards, and other peripherals.
- DDR4 Memory Support: Enjoy fast memory speeds of up to 2666/2400/2133 MHz with support for dual-channel memory architecture.
- Integrated Graphics and Multi-VGA Output: Take advantage of Intel HD Graphics and enjoy multiple display options via HDMI, DVI-D, and D-sub ports.
- Intel H310 Chipset and 6 x USB 2.0/1.1 Ports: With 6 USB 2.0/1.1 ports, you'll have ample connectivity options for peripherals and storage devices.
Exclusive ASUS Technologies
ASUS EZ Flash 3 and CrashFree BIOS 3: Easily update your BIOS with a simple click, and rest assured that your system will remain stable and error-free during the process.
Part ID: #CAN-02144
Last Updated: 1 month ago
Available Deals & Price Comparison
Prices updated dailyHistorical Pricing Trend
Product Specifications
Motherboard Basic Info
BIOS
128 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1, MultilanguageBIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F6 Qfan Control, F3 MyFavorites, Last Modified log, F12 PrintScreen, and ASUS DRAM SPD (SerialPresence Detect) memory information
Form Factor
mATX Form Factor 8.9 inch x 7.3 inch ( 22.6 cm x 18.5 cm )
Motherboard Basic Information
Supported CPU
Intel Socket 1151 9th / 8th Gen Intel Core, Pentium Gold and Celeron Processors Supports Intel 14 nm CPU Supports Intel Turbo Boost Technology 2.0
Chipset
Intel H310
Expansion Slots
PCI
1 x PCIe 3.0/2.0 x16 (x16 mode, gray) 2 x PCIe 2.0 x1
Memory Specifications
Type
DDR4
Motherboard Memory Info
Supported Memory
2666/ 2400/ 2133 MHz Non-ECC, Un-buffered Memory Dual Channel Memory Architecture Supports Intel® Extreme Memory Profile (XMP)
Motherboard Graphics Info
Graphics
Integrated Graphics Processor- Intel HD Graphics support Multi-VGA output support : HDMI/DVI-D/D-Sub ports - Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz - Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz - Supports D-sub with max. resolution 1920 x 1200 @ 60 Hz Supports Intel InTru 3D, Quick Sync Video, Clear Video HD Technology, Insider
Connector & Ports (MB)
HDMI
1 x HDMI
USB (s)
Intel H310 Chipset : 4 x USB 3.1 Gen 1 up to 5Gbps port(s) (2 at back panel, blue, Type-A, 2 at mid-board) Intel H310 Chipset : 6 x USB 2.0/1.1 port(s) (2 at back panel, , 4 at mid-board)
Internal I/O Ports
1 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin) 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s) 1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (both SATA & x2 PCIE mode) 1 x COM port(s) connector(s) 4 x SATA 6Gb/s connector(s) 1 x CPU Fan connector(s) (1 x 4 -pin) 1 x Chassis Fan connector(s) (1 x 4 -pin) 1 x S/PDIF out header(s) 1 x 24-pin EATX Power connector(s) 1 x 4-pin ATX 12V Power connector(s) 1 x Front panel audio connector(s) (AAFP) 1 x Clear CMOS jumper(s) 1 x System panel connector 1 x Speaker connector
Supported Storage
Intel H310 Chipset : 1 x M.2 Socket 3, , with M Key, type 2242/2260/2280 storage devices support (both SATA & x2 PCIE mode)*1 4 x SATA 6Gb/s port(s), gray,
Warranty Information
Manufacturing Warranty
03 years
Part ID: #CAN-02144
Last Updated: 1 month ago
