Status
In Stock
6 listings tracked
Lowest Deal
23,000
Best Deal
Price Range
23,000 to 25,500
Save 11%
Product Description
Engineered by ASUS, this motherboard is featuring a **Micro-ATX** form factor and supporting high-speed **DDR5** memory, providing a reliable foundation for custom desktop systems. PCPartsBD lists the best deal for this item at **23,000 ৳** after tracking live prices across leading BD tech merchants.
Part ID: #CAN-01064
Last Updated: 2 days ago
Available Deals & Price Comparison
Prices updated daily| Retailer | Stock Status | Price | Last Checked | Action |
|---|---|---|---|---|
|
TechLand BD
ASUS B860M AYW GAMING WIFI LGA 1851 DDR5 Micro-ATX Motherboard
|
In Stock | 22,500 | 3 hours ago | |
|
Global Brand PLC
ASUS B860M AYW GAMING WIFI LGA1851 mATX Gaming Motherboard
|
In Stock | 23,300 | 3 hours ago | |
|
Ultra Technology
ASUS B860M AYW GAMING WIFI LGA 1851 Micro-ATX Motherboard
|
In Stock | 25,000 | 2 hours ago | |
|
Skyland BD
ASUS B860M AYW GAMING WIFI LGA 1851 Micro-ATX Motherboard
|
In Stock | 25,000 | 2 hours ago | |
|
Sell Tech
ASUS B860M AYW GAMING WIFI LGA 1851 Micro-ATX Motherboard
|
In Stock | 25,400 | 3 hours ago | |
|
Star Tech
ASUS B860M AYW GAMING WIFI LGA 1851 Micro-ATX Motherboard
|
In Stock | 25,500 | 3 hours ago |
Historical Pricing Trend
Product Specifications
Basic Information
Supported CPU
Supports Intel Core Ultra Processors (Series 2), LGA1851 Supports Intel Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0
Chipset
Intel B860 Chipset
BIOS
256(128+128) Mb Flash ROM, UEFI AMI BIOS
Form Factor
micro-ATX Form Factor 9.6 inch x 8.75 inch (24.4cm x 22.2cm)
Audio
Realtek 7.1 Surround Sound High Definition Audio CODEC* - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking - Supports up to 24-Bit/192 kHz playback Audio Features - Audio Shielding - Premium audio capacitors - Dedicated audio PCB layers * A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.
Expansion Slots
PCI
Intel Core Ultra Processors (Series 2) 1 x PCIe 4.0 x16 slot Intel B860 Chipset 2 x PCIe 4.0 x1 slots
M.2 Socket
Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports Intel Core Ultra Processors (Series 2) M.2_1 slot (Key M), type 2280 (supports PCIe 5.0 x4 mode) Intel B860 Chipset M.2_2 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
Memory
Type
DDR5
Slots
2x DIMM slots
Supported Memory
Supports up to 8800+MT/s (OC), Non-ECC, Un-buffered ,Clocked Unbuffered DIMM (CUDIMM) Dual channel memory architecture DIMM Fit Supports Intel Extreme Memory Profile (XMP) memory module ASUS Enhanced Memory Profile III(AEMPIII)
Maximum Memory
128GB
Graphics
Graphics
1 x HDMITM port Supports 4K@60Hz as specified in HDMI 2.1. VGA resolution support depends on processors' or graphic cards' resolution.
Connector & Ports
HDMI
1 x HDMI
USB (s)
Rear USB (Total 6 ports) 1 x USB 10Gbps port (1 x Type-A) 2 x USB 5Gbps ports (2 x Type-A) 3 x USB 2.0 ports (3 x Type-A)** Front USB (Total 7 ports) 1 x USB 5Gbps connector (supports USB Type-C®)* 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports 2 x USB 2.0 headers support 4 additional USB 2.0 ports** * USB Type-C® power delivery output: max. 5V/3A. ** USB_E1 port, USB_E2 port, USB_E3 port and USB_E4 port share the bandwidth.
LAN Port (s)
1 x Realtek 2.5Gb Ethernet ASUS LANGuard
Wireless Communication module
Wi-Fi 6 1x1 Wi-Fi 6 (802.11ax) Supports 2.4/5GHz frequency band Bluetooth v5.3
Supported Storage
Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports* Intel® Core™ Ultra Processors (Series 2) * M.2_1 slot (Key M), type 2280 (supports PCIe 5.0 x4 mode) Intel® B860 Chipset M.2_2 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode) 4 x SATA 6Gb/s ports
RAID
Intel Rapid Storage Technology supports SATA RAID 0/1/5/10.
Audio
3 x Audio jacks
Internal I/O Ports
Back Panel I/O Ports 1 x USB 10Gbps port (1 x Type-A) 2 x USB 5Gbps ports (2 x Type-A) 3 x USB 2.0 ports (3 x Type-A) 1 x HDMITM port 1 x Wi-Fi module 1 x Realtek 2.5Gb Ethernet port 3 x Audio jacks Internal I/O Connectors Fan and Cooling Related 1 x 4-pin CPU Fan header 2 x 4-pin Chassis Fan headers Power Related 1 x 24-pin Main Power connector 1 x 8-pin +12V CPU Power connector Storage Related 2 x M.2 slots (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 5Gbps connector (supports USB Type-C®) 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports 2 x USB 2.0 headers support 4 additional USB 2.0 ports Miscellaneous 3 x Addressable Gen2 headers 1 x Clear CMOS header 1 x COM Port header 1 x Front Panel Audio header (F_AUDIO) 1 x S/PDIF Out header 1 x SPI TPM header (14-1 pin) 1 x 10-1 pin Front Panel System header
Others
Special Features
ASUS 5X PROTECTION III - DIGI+VRM - LANGuard - Overvoltage protection - SafeSlot Core+ - Stainless-steel back I/O ASUS Q-Design - M.2 Q-Latch - PCIe Slot Q-Release - Q-Dashboard - Q-DIMM - Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) - Q-Slot ASUS Thermal Solution - M.2 heatsink - VRM heatsinks design ASUS EZ DIY - ProCool - Pre-mounted I/O shield Aura Sync - Addressable Gen2 headers
Bundled Software
ASUS Exclusive Software Armoury Crate - Aura Sync - Fan Xpert 2+ - Power Saving ASUS AI Advisor ASUS DriverHub ASUS GlideX ASUS CPU-Z Norton 360 Deluxe (60 Days Free Trial) WinRAR (40 Days Free Trial) UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash - ASUS UEFI BIOS EZ Mode - ASUS MyHotkey
Warranty Information
Manufacturing Warranty
3 Years
Key Features
Model
B860M AYW GAMING WIFI
Supported CPU
Intel Core Ultra Processors (Series 2), LGA 1851
Supported RAM
2x DDR5, Max 128GB, Support up to 8800+MT/s (OC)
Graphics Output
1 x HDMI, Supports 4K@60Hz as specified in HDMI 2.1
Features
2x M.2 Slot, 1 x 2.5Gb LAN, Wi-Fi 6, Bluetooth 5.3
Part ID: #CAN-01064
Last Updated: 2 days ago
The ASUS B860M AYW GAMING WIFI motherboard is a powerful micro-ATX solution designed for Intel Core Ultra Processors (Series 2) with the LGA1851 socket. It fully supports Intel Turbo Boost Technology 2.0 and Turbo Boost Max Technology 3.0. It is powered by the Intel B860 chipset and can support up to 128GB of DDR5 memory with speeds of 8800+MT/s (OC), as well as dual-channel architecture, Intel XMP, and ASUS Enhanced Memory Profile III. The ASUS B860M AYW GAMING WIFI Motherboard features an HDMI 2.1 port that supports 4K at 60Hz. The expansion possibilities include one PCIe 4.0 x16 slot and two PCIe 4.0 x1 slots. The storage is sturdy, with two M.2 slots and four SATA 6Gb/s connectors. The M.2_1 slot supports PCIe 5.0 x4, while the M.2_2 slot supports PCIe 4.0 x4, with RAID 0/1/5/10 capability provided by Intel Rapid Storage Technology. This ASUS B860M AYW GAMING WIFI LGA 1851 Micro-ATX Motherboard supports Realtek 2.5Gb Ethernet with ASUS LANGuard, Wi-Fi 6 (1x1) with dual-band compatibility, and Bluetooth v5.3. Rear I/O features one USB 10Gbps Type-A, two USB 5Gbps Type-A, and three USB 2.0 ports, while front USB compatibility includes one USB 5Gbps Type-C connector, one 5Gbps header, and two USB 2.0 headers that provide four additional ports. The ASUS B860M AYW GAMING WIFI Micro-ATX Motherboard features audio driven by the Realtek 7.1 Surround Sound codec, which supports 24-bit/192kHz playback, audio shielding, quality capacitors, and dedicated PCB layers. Internal I/O includes fan headers, power connectors, storage connectors, several USB headers, and addressable Gen2 RGB. ASUS' features include 5X Protection III, Q-Design elements for easier DIY building, thermal solutions for VRM and M.2, and Aura Sync lighting. The ASUS B860M AYW GAMING WIFI LGA 1851 Micro-ATX Motherboard also includes UEFI BIOS with ASUS EZ DIY features, Armoury Crate, Fan Xpert 2+, ASUS AI Advisor, and support for Windows 11 and Windows 10 64-bit. It is a small, high-performance board that is excellent for modern gaming and productivity projects.Buy ASUS B860M AYW GAMING WIFI Motherboard from Star TechIn Bangladesh, you can get original ASUS B860M AYW GAMING WIFI Motherboard From Star Tech. We have a large collection of latest Asus Motherboard to Purchase for your Desktop. Order Online Or Visit your Nearest Star Tech Shop to get yours at lowest price. The ASUS B860M AYW GAMING WIFI Motherboard comes with a 3-year Warranty.
