Specification Technical Information  Supported CPU Supports 12th Gen Intel Core Processors (LGA1700) Digi Power Design 13 Power Phase Design Supports Intel Hybrid Technology Supports Intel Turbo Boost Max 3.0 Technology Chipset Intel H470 Memory Dual Channel DDR4 Memory Technology Supports DDR4 2933 / 2800 / 2666 / 2400 / 2133 Non-ECC, Un-Buffered Memory Supports ECC UDIMM Memory Modules (Operate In Non-ECC Mode) Supports Intel Extreme Memory Profile (XMP) 2.0 15μ Gold Contact In DIMM Slots Graphics - Hardware Accelerated Codecs: AVC/H.264, HEVC/H.265 8bit, HEVC/H.265 10bit, VP8, VP9 8bit, VP9 10bit, MPEG 2, MJPEG, VC-1 - Graphics, Media & Compute: Microsoft DirectX 12, OpenGL 4.5, Intel Built In Visuals, Intel Quick Sync Video, Hybrid / Switchable Graphics, OpenCL 2.1 - Display & Content Security: Rec. 2020 (Wide Color Gamut), Microsoft PlayReady 3.0, Intel SGX Content Protection, UHD Blu-Ray Disc - Three Graphics Output Options: D-Sub, DVI-D And HDMI - Supports Triple Monitor - Supports HDMI 1.4 With Max. Resolution Up To 4K X 2K (4096x2160) @ 30Hz - Supports DVI-D With Max. Resolution Up To 1920x1200 @ 60Hz - Supports D-Sub With Max. Resolution Up To 1920x1200 @ 60Hz - Supports Auto Lip Sync, Deep Color (12bpc), XvYCC And HBR (High Bit Rate Audio) With HDMI 1.4 Port (Compliant HDMI Monitor Is Required) - Supports HDCP 2.3 With DVI-D And HDMI 1.4 Ports - Supports 4K Ultra HD (UHD) Playback With HDMI 1.4 Port Slots 1 X PCI Express 3.0 X16 Slot* 2 X PCI Express 3.0 X1 Slots 1 X M.2 Socket (Key E), Supports Type 2230 WiFi/BT PCIe WiFi Module Supported Storage 8 X SATA3 6.0 Gb/S Connectors* 1 X Hyper M.2 Socket (M2_1, Key M), Supports Type 2260/2280 PCIe Gen4x4 (64 Gb/S) Mode** 1 X Ultra M.2 Socket (M2_2, Key M), Supports Type 2260/2280 SATA3 6.0 Gb/S & PCIe Gen3x4 (32 Gb/S) Modes** 1 X Hyper M.2 Socket (M2_3, Key M), Supports Type 2260/2280/22110 PCIe Gen4x4 (64 Gb/S) Mode LAN Gigabit LAN 10/100/1000 Mb/S Giga PHY Intel I219V Supports Wake-On-LAN Supports Lightning/ESD Protection Supports Energy Efficient Ethernet 802.3az Supports PXE Audio HD Audio Jacks: Line In / Front Speaker / Microphone USB Port 2 X USB 2.0 Headers (Support 4 USB 2.0 Ports) (Supports ESD Protection) 2 X USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 Ports) (Supports ESD Protection) 2 X USB 3.2 Gen2 Ports (10 Gb/S) (ReDriver) (Supports ESD Protection) 2 X USB 3.2 Gen1 Ports (Supports ESD Protection) 2 X USB 2.0 Ports (Supports ESD Protection) Internal I/O Ports 1 X Print Port Header 1 X COM Port Header 1 X Chassis Intrusion And Speaker Header 1 X CPU Fan Connector (4-Pin) 1 X CPU/Water Pump Fan Connector (4-Pin) (Smart Fan Speed Control) 2 X Chassis/Water Pump Fan Connectors (4-Pin) (Smart Fan Speed Control) 1 X 24 Pin ATX Power Connector 1 X 8 Pin 12V Power Connector1 X Front Panel Audio Connector 2 X USB 2.0 Headers (Support 3 USB 2.0 Ports) (Supports ESD Protection) - 2 X USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 Ports) (Supports ESD Protection) DIMENSIONS 12.0-In X 9.6-In, 30.5 Cm X 24.4 Cm Form Factor Micro ATX Form Factor: 8.9-In X 7.4-In, 22.6 Cm X 18.8 Cm Solid Capacitor Design BIOS 128Mb AMI UEFI Legal BIOS With Multilingual GUI Support ACPI 6.0 Compliant Wake Up Events SMBIOS 2.7 Support CPU Core/Cache, GT, DRAM, VPPM, PCH 1.05V, VCCST, VCCSA Voltage Multi-Adjustment HDMI 1 X HDMI Port Warranty 3 Years ASRock H470M-HDV/M.2 10th Gen Micro ATX Motherboard The ASRock H470M-HDV/M.2 Micro ATX Motherboard supports 10th Gen Intel Core Processors (Socket 1200). It has a 7 Power Phase Design, it offers enhanced performance with the lowest temperature for advanced gamers. Complete with all three types of most used connectors. It features Dual Channel DDR4 Memory Technology and supports DDR4 2933/ 2800/ 2666 / 2400 / 2133 non-ECC, un-buffered memory. It has 2 x DDR4 DIMM Slots. It comes with a 7.1 CH HD Audio (Realtek ALC897 Audio Codec). It supports Intel Turbo Boost Max 3.0 Technology. It comes with 128Mb AMI UEFI Legal BIOS with multilingual GUI support. It has a High-Density Glass Fabric PCB design that reduces the gaps between the PCB layers to protect the motherboard against electrical shorts caused by humidity. You can also easily optimize your system and keep your motherboard up to date with ASRock Live Update & APP Shop...
