Product Description
Unlock Unbeatable Performance with the ASRock B650M Pro RS WiFi AM5 Micro ATX Motherboard
Designed for gamers, content creators, and PC enthusiasts, this powerful motherboard delivers exceptional speed, efficiency, and versatility. Built to support the latest AMD Ryzen 9000, 8000, and 7000 Series processors, the ASRock B650M Pro RS WiFi AM5 Micro ATX Motherboard is the perfect foundation for your next high-performance build.
Key Features and Benefits
- Supports AMD Ryzen 9000, 8000, and 7000 Series Processors
- 8+2+1 Power Phase VRM Design with Dr.MOS Technology
- Up to 4 DDR5 DIMMs in Dual-Channel Mode with speeds up to 7200+ MHz (OC)
- 1 PCIe 4.0 x16 Slot and 1 PCIe 3.0 x16 Slot for Flexible Graphics Cards and Peripheral Installations
- Robust Connectivity with 2.5G LAN, Wi-Fi 6E, and Bluetooth 5.2
ASRock's Innovative Technologies
The ASRock B650M Pro RS WiFi AM5 Micro ATX Motherboard is built with cutting-edge technologies that enhance performance, stability, and user experience. With the 8+2+1 Power Phase VRM design featuring Dr.MOS technology, the motherboard provides stable and efficient power delivery for demanding tasks. Additionally, the Realtek ALC897 7.1 Channel HD Audio Codec and Nahimic Audio deliver an immersive sound experience, while the robust storage options, including 4 SATA3 ports and 3 M.2 slots, cater to both high-speed NVMe SSDs and traditional SATA drives.
Part ID: #CAN-01301
Last Updated: 1 month ago
Available Deals & Price Comparison
Prices updated daily| Retailer | Stock Status | Price | Last Checked | Action |
|---|---|---|---|---|
|
Star Tech
ASRock B650M Pro RS WiFi AM5 Micro ATX Motherboard
|
In Stock | Call for Price | 1 week ago | |
|
Creatus Computer
ASRock B650M Pro RS WiFi AM5 Micro ATX Motherboard
|
In Stock | 19,899 | 5 hours ago | |
|
TechLand BD
ASRock B650M Pro RS WiFi AM5 AMD Motherboard
|
In Stock | 19,999 | 5 hours ago | |
|
Ultra Technology
ASRock B650M Pro RS WiFi AM5 Micro ATX Motherboard
|
In Stock | 20,300 | 4 hours ago | |
|
Nexus Computer
ASRock B650M Pro RS WiFi AMD Motherboard
|
In Stock | 23,650 | 4 hours ago | |
|
PC House
ASRock B650M Pro RS WiFi AMD Motherboard
|
In Stock | 24,700 | 4 hours ago | |
|
Sell Tech
ASRock B650M Pro RS WiFi AM5 Micro ATX Motherboard
|
Check Stock | 19,999 | 4 hours ago |
Historical Pricing Trend
Product Specifications
Basic Information
Supported CPU
Supports AMD Socket AM5 Ryzen 9000, 8000 and 7000 Series Processors
Chipset
AMD B650
BIOS
- 256Mb AMI UEFI Legal BIOS with GUI support
Form Factor
- Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm - 2oz Copper PCB
Audio
- 7.1 CH HD Audio (Realtek ALC897 Audio Codec) - Nahimic Audio
Expansion Slots
PCI
CPU: - 1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode* - 1 x PCIe 3.0 x16 Slot (PCIE2), supports x4 mode* Chipset: - 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module - Supports AMD CrossFire™ - 15μ Gold Contact in VGA PCIe Slot (PCIE1)
Memory
Type
DDR5
Slots
- 4 x DDR5 DIMM Slots
Supported Memory
- Dual Channel DDR5 Memory Technology - Supports DDR5 ECC/non-ECC, un-buffered memory up to 7200+(OC)* - Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules
Maximum Memory
Max. 256GB
Graphics
Graphics
Integrated AMD RDNA graphics (Actual support may vary by CPU) - 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz - 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 4K 120Hz
Connector & Ports
HDMI
1x HDMI
Display Port (s)
1x DisplayPort 1.4
USB (s)
- 1 x USB 3.2 Gen2 Type-C (Rear) - 1 x USB 3.2 Gen2 Type-A (Rear) - 1 x USB 3.2 Gen1 Type-C (Front) - 6 x USB 3.2 Gen1 Type-A (2 Rear, 4 Front) - 8 x USB 2.0 (4 Rear, 4 Front)
LAN Port (s)
- 2.5 Gigabit LAN 10/100/1000/2500 Mb/s - Dragon RTL8125BG - Supports Dragon 2.5G LAN Software - Smart Auto Adjust Bandwidth Control - Visual User Friendly UI - Visual Network Usage Statistics - Optimized Default Setting for Game, Browser, and Streaming Modes - User Customized Priority Control
Wireless Communication module
- 802.11ax Wi-Fi 6E Module - Supports IEEE 802.11a/b/g/n/ac/ax - Supports Dual-Band 2x2 with extended 6GHz band* support - 2 antennas to support 2 (Transmit) x 2 (Receive) diversity technology - Supports Bluetooth 5.2 + High speed class II - Supports MU-MIMO
Supported Storage
CPU: - 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2260/2280 PCIe Gen5x4 (128 Gb/s) mode* Chipset: - 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode* - 1 x M.2 Socket (M2_3, Key M), supports type 2260/2280 PCIe Gen4x2 (32 Gb/s) mode* - 4 x SATA3 6.0 Gb/s Connectors
RAID
- Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices - Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices
Audio
3 x Audio jacks
Internal I/O Ports
Rear Panel I/O - 2 x Antenna Mounting Points - 1 x HDMI Port - 1 x DisplayPort 1.4 - 1 x USB 3.2 Gen2 Type-A Port (10 Gb/s) - 1 x USB 3.2 Gen2 Type-C Port (10 Gb/s) - 2 x USB 3.2 Gen1 Ports - 4 x USB 2.0 Ports - 1 x RJ-45 LAN Port - 1 x BIOS Flashback Button - HD Audio Jacks: Line in / Front Speaker / Microphone Connector - 1 x Power LED and Speaker Header - 1 x RGB LED Header* - 3 x Addressable LED Headers** - 1 x CPU Fan Connector (4-pin)*** - 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)**** - 3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)***** - 1 x 24 pin ATX Power Connector - 1 x 8 pin 12V Power Connector (Hi-Density Power Connector) - 1 x Front Panel Audio Connector - 1 x Thunderbolt™ AIC Connector (5-pin) (Supports ASRock Thunderbolt™ 4 AIC Card) - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) - 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports) - 1 x Front Panel Type C USB 3.2 Gen1 Header
TPM (Trusted Platform Module )
- 1 x SPI TPM Header
Others
Special Features
Superb Productivity - PCIe Gen5 (M.2) - Dual Channel DDR5 Rock-Solid Durability - 8+2+1 Power Phase, 50A Dr.MOS - Pre-Installed I/O Shield Ultrafast Connectivity - 2.5G LAN EZ Update - BIOS Flashback Button - ASRock Auto Driver Installer
Bundled Software
Software - ASRock Motherboard Utility (A-Tuning) - ASRock Dragon 2.5G LAN Software - ASRock Polychrome SYNC* UEFI - ASRock Full HD UEFI - ASRock Auto Driver Installer - ASRock Instant Flash
Warranty Information
Manufacturing Warranty
3 Years Warranty
Key Features
Model
B650M Pro RS WiFi
Supported CPU
Ryzen 9000/8000/ 7000 Series Processors for Socket AM5
Supported RAM
4x DDR5, up to 256GB, 7200+(OC)
Graphics Output
1x HDMI, 1x DisplayPort
Features
2.5 Gigabit LAN 10/100/1000/2500 Mb/s, Wi-Fi 6E
Part ID: #CAN-01301
Last Updated: 1 month ago
